NOTE: If cluster installation fails with the message Could not get the system drive
for the cluster node... or Setup was unable to run the installation in
remote machine..., confirm that the WMI service is running. To use the HP EVA Cluster
Extension cluster-wide installation feature, the WMI service must be running.
On Windows Server 2012, installation of the CLX product registers the CLX resource type, and
registration of resource type copies the CLX resource DLL files clxevamscs.dll and
clxevavmmscs.dll to the %SystemDrive%\Windows\Cluster folder on all the cluster
nodes. Uninstallation of CLX does not remove these files, instead they are renamed. After the
uninstallation is complete, the files must be manually removed.
When you complete the installation of the CLX product on all the cluster nodes, the cluster service
must be restarted on all the cluster nodes. This must be done if any CLX resource (Cluster Extension
EVA or Cluster Extension EVA for VM Management) exists in the cluster after you have completed
the uninstallation of the CLX product on all the cluster nodes.
On Windows Server 2012 Server Core, apart from failover cluster, the feature
RSAT-Clustering-PowerShell having the display name Failover Cluster Module for Windows
PowerShell must be installed. This feature is required by the CLX installer for registration and
un-registration of CLX resources during the installation.
If you are installing CLX product on a cluster that contains both Server Core and Non-Server Core
nodes, then you must install the CLX product from the Non-Server Core cluster node.
Table 1 Windows remote installation error codes
Corrective actionDescriptionERROR code
N/AInstallation was successful on the local
cluster node.
ERROR_INSTALLATION_SUCCESS
N/AHP EVA Cluster Extension was
successfully removed from the local
cluster node.
ERROR_REMOVAL_SUCCESS
N/AHP EVA Cluster Extension was
successfully repaired on the local
cluster node.
ERROR_REPAIR_SUCCESS
N/AHP EVA Cluster Extension was
successfully modified on the local
cluster node.
ERROR_MODIFY_SUCCESS
Run the setup on the local cluster node.Setup failed on the local cluster node.ERROR_READ_INPUT_FILE_FAILED
The silent input file is corrupted.
Run the setup on the local cluster node.Setup failed on the local cluster node.ERROR_INVALID_HANDLE
Internal Error. Could not invoke the DLL.
Run the setup on the local cluster node.Setup failed on the local cluster node.SILENT_INPUT_FILE_CORRUPTED
The silent input file is corrupted or
could not be found.
Run the setup on the local cluster node.Setup failed on the local cluster node.LOCAL_NODE_NAME_NOT_FOUND
Could not find the local node name.
Register the resource type by running
the following cluster command:
Installation completed on the local
cluster node.
ERROR_CLXMSCS_REGISTER_FAILED
cluster restype "Cluster
Setup was unable to register the
resource type Cluster Extension EVA.
Extension EVA" /create
/dll:clxevamscs.dll
/type:"Cluster Extension
EVA". Powershell cmdlets can also be
