Use either disk enclosure with Large or Small Form Factor, single or dual controller array heads. Each ship with two .5m
mini-SAS to mini-SAS cables.
HP StorageWorks P2000 Dual I/O 3.5-inch 12 Drive Disk Enclosure AP843A
HP StorageWorks D2700 Dual I/O 2.5-inch 25 Drive Disk Enclosure AJ941A
HP StorageWorks P2000 Drive Enclosure I/O Module
(Only used in conjunction with the P2000 blank chassis (AP838A) if a single I/O disk
enclosure is desired. No cable included)
AP844A
Step 2c - SAS Cable Options
miniSAS to miniSAS Cables :
Connecting P2000 G3 FC or SAS controller to a JBOD if a longer cable is desired. Also
used for attaching the P2000 G3 SAS host ports to servers
HP Ext miniSAS to miniSAS 2m Cable 407339-B21
Step 3 - Other P2000 G3 Options
Choose optional AC Power Cords (2 required)
NOTE : Two PDU cables: one 142263-008 (Black) and one 1422633-013 (Grey), ship standard with all AC-
powered enclosures.
Power Cord, 220/240 VAC, (US/Canada/Mexico) 227099-001
Power Cord, (Australia/China/New Zealand) 227098-001
Power Cord, (Central Europe) 157215-001
Power Cord, (United Kingdom/Hong Kong) 157216-001
Power Cord, (Switzerland) 157219-001
Power Cord, (Italy) 157217-001
Power Cord, (Denmark) 157218-001
Power Cord, (Japan) 139867-001
Power Cord, (South East Asia/India) 157220-001
Step 4a - Choose Supported Options For Fibre Channel Infrastructure
Fibre Channel
Host Bus Adapters -
X86 servers
Model Description Part Number
BladeSystem c-Class Fibre Channel Mezzanine HBAs
QLogic QMH2562 8Gb FC HBA for HP c-Class BladeSystem 451871-B21
HP BLc Emulex LPe1205- 8Gb FC HBA for HP c-Class BladeSystem 456972-B21
Lpe1105-HP 4Gb FC HBA for HP c-Class BladeSystem 403621-B21
QMH2462 4Gb FC HBA for HP c-Class BladeSystem Windows and Linux 403619-B21
Brocade 804 8Gb FC HBA for HP BladeSystem c-Class, Windows, VMware,
Linux
590647-B21
StorageWorks Fibre Channel HBAs
NOTE: Please visit www.hp.com/go/fchba for product details and
www.hp.com/storage/spock for compatibility details.
Brocade Fibre Channel HBAs
HP StorageWorks 81B PCI-e FC HBA Single Port AP769A
HP StorageWorks 82B PCI-e FC HBA Dual Port AP770A
HP StorageWorks 41B 4Gb PCI-e FC HBA AP767A
HP StorageWorks 42B 4Gb Dual-Port PCI-e FC HBA AP768A
Emulex Fibre Channel HBAs
HP StorageWorks 81E PCI-e FC HBA Single Port AJ762A
HP StorageWorks 82E PCI-e FC HBA Dual Port AJ763A
HP StorageWorks FC2142 4Gb PCI-e HBA A8002A
HP StorageWorks FC2242 Dual Channel 4Gb PCI-e HBA A8003A
QLogic Fibre Channel HBAs
HP StorageWorks 81Q PCI-e FC HBA Single Port AK344A
HP StorageWorks 82Q PCI-e FC HBA Dual Port AJ764A
HP StorageWorks FC1142 4Gb PCI-e HBA AE311A
HP StorageWorks FC1242 Dual Channel 4Gb PCI-e HBA AE312A
Fibre Channel
Host Bus Adapters -
Integrity servers
Integrity HP PCI-X 2.0 1Port 4Gb AB378B
HP PCI-X 2.0 2Port 4Gb Fibre Channel HBA AB379B
HP PCIe 2Port 4Gb Fibre Channel HBA AD300A
QuickSpecs
HP StorageWorks P2000 G3 Modular Smart Array Systems
Configuration Information
