WebTools Functionality
Some functionality formerly residing in the WebTools 6.0 application has been moved to DCFM. The
following table details these changes.
TABLE 14
Function WebTools 6.0 DCFM Comments
FCIP Tunnel
Configuration
Port Admin Module > GigE tab Configure > FCIP Tunnel Viewing FCIP tunnels is still
supported in WebTools 6.1.1, but
New, Edit Config, and delete are
only available in DCFM.
GigE Ports Interface Port Admin Module > GigE tab Configure > FCIP Tunnel
GigE Ports Route Port Admin Module > GigE tab Configure > FCIP Tunnel
Fabric Summary Reports > Fabric Summary Monitor > Reports > Fabric Summary
Report
Fabric Events Monitor > Fabric Events Monitor > Logs > Events
Zoning
Zone database
summary print
Zone Admin Configure > Zoning
Zoning report for both online and offline
database.
Define Device Alias Zone Admin Configure > Zoning
Remove Offline or
Inaccessible Devices
Zone Admin Configure > Zoning
Replace/Replace All zone members by
selecting the offline devices from the zone
tree. Offline devices have an unknown
overlay badge with good visibility.
Device Accessibility
Matrix (Enterprise
edition only)
Zone Admin Configure > Zoning
the Compare dialog provides the
Storeage-Host and Host-Storage view in a
tree representation that is comparable to
the Device Accessibility Matrix when all
devices are selected.
Analyze Zone Config
(Enterprise edition only)
Zone Admin 1 Configure > Zoning:
Reverse Find in the Zoning dialog
provides the view of the zoned and
unzoned devices in the fabric if all
zone members are selected for Find.
2 Device Tree and Topology:
Connected End Devices - Custom
Display from the top level in the main
frame provides the device tree and
topology view for all the zoned
devices if all zones are selected in
the active zone configuration.
