Installing the Smart Card driver on the remote client
1. Complete steps 1-4 in “Installing the Smart Card driver on the local client” on page 32.
2. Run the following commands in order to support remote clients (Web Start).
> cd /usr/lib
> ln –s /opt/pcsc/lib/libpcsclite.so .
NOTE
If a soft link exists on libpcsclite.so, you must ensure that the final file is linked to
/opt/pcsc/lib/libpcsclite.so.xxx. You can backup the original one first. See the example
below.
> ls –l libpcsc*
lrwxrwxrwx 1 root root 20 Aug 4 16:16 libpcsclite.so ->
libpcsclite.so.1.0.0
lrwxrwxrwx 1 root root 20 Jun 4 12:30 libpcsclite.so.1 ->
libpcsclite.so.1.0.0
lrwxrwxrwx 1 root root 34 Aug 5 14:36 libpcsclite.so.1.0.0
> mv libpcsclite.so.1.0.0 libpcsclite.so.1.0.0.org
> ln -s /opt/pcsc/lib/libpcsclite.so.1.0.0 libpcsclite.so.1.0.0
> ls –l libpcsc*
lrwxrwxrwx 1 root root 20 Aug 4 16:16 libpcsclite.so ->
libpcsclite.so.1.0.0
lrwxrwxrwx 1 root root 20 Jun 4 12:30 libpcsclite.so.1 ->
libpcsclite.so.1.0.0
lrwxrwxrwx 1 root root 34 Aug 5 14:36 libpcsclite.so.1.0.0 ->
/opt/pcsc/lib/libpcsclite.so.1.0.0
-rwxr-xr-x 1 root root 35428 Aug 4 16:17 libpcsclite.so.1.0.0.org
Detecting and correcting a default Linux Smart Card driver
This section only applies to Linux system. Some Linux systems may already provide a default Smart
Card driver and have their own setup to activate it. In this case, you must still use the driver
provided with the Management application. Otherwise, there could be an incompatibility issue
between the driver and native library which might cause driver detection failure. Complete the
following steps to discover whether a default driver already exists and how to reconfigure the driver
environment.
1. Detect a different smart card driver by running the following commands:
> cd /
> find . –name pcscd –print
If the results contain “pcscd” and it is not located under /opt/pcsc or /etc/init.d/pcscd, it
means there is a different driver exists on the system.
2. Make sure the pcscd file on the /etc/init.d directory is linked to /opt/pcsc/pcscctl by running
the following commands:
> cd /etc/init.d
> ls –l pcscd
lrwxrwxrwx 1 root root 17 Jul 28 01:29 pcscd -> /opt/pcsc/pcscctl
