Message
ID
Message Text Explanation
the HDLM User's Guide for instructions
how to execute the DLMgetras utility.
aa...aa: Error Code
(character string)
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
dlmodmset utility, see
KAPL08001 to KAPL09000
on page 8-55.
KAPL10805-
I
The setup of the HDLM execution
environment ODM will be changed.
aa...aa = bb...bb. Is this OK? [y/n]:
Details
We recommend that you
report the setup of the
HDLM execution
environment ODM that you
want to change to the user
for confirmation.
aa...aa: Lun Reset,
Online(E) IO Block
(character string)
bb...bb: on, off (character
string)
Action
Enter y to execute setup,
or enter n to cancel.
KAPL10806-
W
The entered value is invalid. Re-enter [y/
n]:
Details
A value other than y or n
has been entered for a [y/
n] request. Enter [y/n].
Action
Enter y or n.
KAPL10807-
E
The entered value is invalid. The
operation stops.
Details
An invalid response was
sent three times
consecutively to a request.
Action
Re-execute the dlmodmset
utility.
KAPL10808-
I
The user terminated the operation. Details
The utility has been
terminated because n was
sent to a request.
Action
None.
KAPL10809-
W
No operation has been specified. Details
8-110
Messages
Hitachi Dynamic Link Manager User Guide for AIX
®
