Hitachi Dynamic Link Manager Software Users Guide for AIX (7.6)

# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -lbpathusetimes
Times Same Path Was Used : 20
KAPL01001-I The HDLM command completed normally. Operation name
= view, completion time = yyyy/mm/dd hh:mm:ss
#
Example 8
The following example shows how to display the number of times the
same path can be used for extended load balancing:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -expathusetimes
Times Same ExPath Was Used : 100
KAPL01001-I The HDLM command completed normally. Operation name
= view, completion time = yyyy/mm/dd hh:mm:ss
#
To Display Path Information
When displaying path information, if you specify either the -item or -c
parameter and also specify the -path parameter, you can select the items to
display and display a summary of path information. This section describes
each parameter, path information and displayed items.
Parameters to display path information:
-path
When you specify the -path parameter and do not specify either the -c or
-item parameter, the information will be displayed about the HDLM
managed paths without abbreviating or selecting items.
In the sub-parameters (following -path), you can filter the paths to be
listed using -hdev and sort the list using -srt. When you omit both
parameters, the command displays information for all the paths in order
of increasing AutoPATH_IDs.
For details on what is displayed in each item, see
Table 6-12 Displayed
Path Information on page 6-48.
AutoPATH_IDs displayed by the -path parameter depend on the sequence
in which HDLM detects the paths after when a host is started up. Because
of this, make sure that you use the path name PathName to identify a
path.
The sub-parameters are as follows:
-hdev host-device-name
Displays information only for the paths accessing the specified host
device.
Specify hdisk name for host-device-name.
The host-device-name string is case -sensitive.
-stname
6-42
Command Reference
Hitachi Dynamic Link Manager User Guide for AIX
®
