Parameter
and
program
informatio
n to be
displayed
Item Description
view -sys -lic operation is executed, (ndays
after) appears if there are n days left until the
license period expires.
• When there are 100 days left until the license
period (2006/08/21) expires
2006/08/21(100days after)
-audlog
Information
about audit
log data
collection
settings
Audit Log Settings for audit log data collection:
• Whether collection is enabled:
on: Enabled
off: Disabled
• Audit log data collection level:
When audit log data collection is on, the
collection level that has been set is displayed
within the parentheses following on. The
collection level indicates a severity level. A value
from 0 to 7 is displayed as the collection value.
Audit Log
Category
The categories of audit log data to be output are
displayed. When more than one category is
displayed, commas (,) are used as separators.
ss: StartStop
a: Authentication
ca: ConfigurationAccess
If all the above categories are specified, all is
displayed.
If the collection of audit log data is disabled, a
hyphen (-) is displayed.
Audit Log
Facility
The name of the audit log facility is displayed. user,
local0, local1, local2, local3, local4, local5,
local6, or local7 is displayed.
If the collection of audit log data is disabled, a
hyphen (-) is displayed.
-
lbpathuse
times
The
number of
times the
same path
can be
used for
load
balancing
Times Same
Path Was Used
The number of times the same path can be used for
I/O operations when the Round Robin (rr), Least I/
Os (lio), or Least Blocks (lbk) algorithm is used for
load balancing.
If you used Global Link Manager to set the number
of times the same path can be used in units of LUs,
an asterisk (*) is added after the value.
