Legend:
Optional: If a key and its setting are not specified, one of the following
values will be used:
¢
For a new installation
The default value will be used.
¢
For an upgrade installation or re-installation:
The previous setting will be inherited.
Note:
Setting of audit logs is not supported.
#1
Enter one key and one setting per line.
#2
If the value is not of an allowable type, an error will occur.
For details about the functions set by these keys, see set (Sets Up the
Operating Environment) on page 6-17.
#3
You can specify this key only in the following cases:
¢
For a new installation:
When on is specified for the auto_failback key in the installation
information settings file
¢
For an upgrade installation or re-installation:
When on is specified for the auto_failback key in the installation
information settings file, or when automatic failback is enabled in the
installation pre-settings
#4
If you want to enable intermittent error monitoring, specify this key after
specifying the auto_failback and auto_failback_interval keys.
#5
The checking interval can be set regardless of whether the dynamic I/O
path control function is enabled or disabled.
The following shows an example of an edited installation information settings
file.
[INSTALLATION_SETTINGS]
installfile_location=/dev/cd0
logdir=/var/tmp
licensekeyfile=/var/tmp/hdlm_license
licensekey=/var/DLM/dlm.lic_key
driver_config=y
restart=n
[DISK_DEFAULT_SETTINGS]
reserve_policy=PR_exclusive
[ODM_SETTINGS]
odm_lun_reset=off
