Sorts the CHA port information by the storage system model IDs
(Product), storage system serial numbers (S/N), and CHA port
numbers (ChaPort).
-t
Does not display the title for each information item.
To Display the Correspondences Between hdisks, OS Management Path IDs, and
LDEVs
-drv
Use this parameter to display the PathIDs, hdisk name, OS management
path IDs, and information about the LDEVs in a storage system (identified
by the storage system model ID, serial number, and LU number,
separated by periods).
For details on the contents of each display item, see Table 6-20 Items
Displayed as the Correspondences Between hdisks, OS Management Path
IDs, and LDEVs on page 6-67.
-t
Does not display the title for each information item.
Table 6-20 Items Displayed as the Correspondences Between hdisks,
OS Management Path IDs, and LDEVs
Item Description
PathID
AutoPATH_ID indicated by a decimal number.
AutoPATH_ID is assigned when the host is restarted or
when a path configuration is changed. When a new LU
was added and the host has not been restarted,
AutoPATH_ID is assigned to each path of the LU,
AutoPATH_ID is assigned when you execute the cfgmgr
command.
HDevName
Host device name.
Hdisk name is displayed.
OSPathID
OS management path ID.
LDEV
The model ID, serial number, and iLU number for the
storage system, separated by periods. The information
about an LDEV can physically identify an LU.
Example
To display corresponding information about PathIDs, hdisks,
OSPathIDs, and LDEVs
# /usr/DynamicLinkManager/bin/dlnkmgr view -drv
PathID HDevName OSPathID LDEV
000000 hdisk0 00000 9500V.0051.0005
000001 hdisk1 00000 9500V.0051.0015
000002 hdisk2 00000 9500V.0051.0020
000003 hdisk0 00001 9500V.0051.0005
