To Display LU Information
When displaying LU information, if the -item parameter, -c parameter, or
the -c -item parameter is specified at the same time as the -lu parameter,
you can add and display items and display a summary of LU information. This
section describes each parameter and the LU information and displayed
items.
To display LU information
-lu
When neither the -c nor -item parameter is specified with the -lu
parameter, the information about the LU recognized by HDLM is displayed
without selecting items to be displayed or displaying a summary. The
sorting key is iLU and its configuration information is displayed for each
LU.
By using the subsequent parameter (-hdev or -pathid), you can filter the
LU information to be displayed. If you do not specify -hdev or -pathid,
the information about all LUs recognized by HDLM is displayed. For details
on the contents of each displayed item, see
Table 6-17 Displayed LU
Information on page 6-59.
The subsequent parameters are:
-hdev host-device-name
Filters the information only for the paths accessing the specified host
device.
Specify hdisk name for host-device-name.
The host-device-name string is case-sensitive.
-pathid AutoPATH_ID
Use this parameter to display only the information about the LU that
is connected to the path with that specified AutoPATH_ID.
-t
Omits the title for each information item.
Example
The following example shows how to display the LU information
without selecting items to be displayed:
# /usr/DynamicLinkManager/bin/dlnkmgr view -lu
Product : USP
SerialNumber : 0014010
LUs : 10
iLU HDevName OSPathID PathID Status
003A hdisk0 00000 000000 Online
00001 000001 Online
003B hdisk1 00000 000002 Online
00001 000003 Online
003C hdisk2 00000 000004 Online
00001 000005 Online
003D hdisk3 00000 000006 Online
