Maintenance and Service Guide 7–1
7
Screw listing
This section provides specification and reference information for the screws used in the computer. All screws
except the display screws listed in this section are available in the Screw Kit, spare part number 516498-001.
Display screw are available in the Display Screw Kit, spare part number 512362-001.
Phillips PM2.0×3.0 screw
Where used: 2 screws that secure the optical drive bracket to the computer.
Color Quantity Length Thread Head diameter
Silver 13 3.0 mm 2.0 mm 5.0 mm
