System information
Table Of Contents
- HP Pavilion dv6 Entertainment PC
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures
- Preliminary replacement requirements
- Component replacement procedures
- Service tag
- Computer feet
- Battery
- Webcam/microphone module
- Optical drive
- Memory module
- TV tuner module
- RTC battery
- Hard drive
- WLAN module
- Switch cover and keyboard
- Power button board
- Bluetooth module
- Display assembly
- Speaker
- Top cover
- Modem module
- Audio/infrared board
- USB board
- Power connector cable
- System board
- TV tuner module cable
- Modem module cable
- Fan/heat sink
- Processor
- Setup Utility
- Specifications
- Computer specifications
- 15.6-inch WXGA display specifications
- Hard drive specifications
- Blu-ray ROM DVD±R/RW SuperMulti DL Drive specification
- DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive specifications
- System DMA specifications
- System interrupt specifications
- System I/O address specifications
- System memory map specifications
- Screw listing
- Backup and Recovery
- Connector pin assignments
- Power cord set requirements
- Recycling
- Index
6–6 Maintenance and Service Guide
Specifications
System I/O address specifications
I/O address (hex) System function (shipping configuration)
000 - 00F Direct memory access controller
000 - CF7 PCI bus
010 - 01F Motherboard resources
020-021 Program interrupt controller
02E-02F Motherboard resources
040-043 System timer
060 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QLB
061 System speaker
062 Microsoft ACPI-Compliant Embedded Controller
064 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QL
066 Microsoft ACPI-Compliant Embedded Controller
070-071 System CMOS/real time clock
072-073 Motherboard resources
080 Motherboard resources
081-08F Direct memory access controller
092 Motherboard resources
0A0-0A1 Program interrupt controller
0B0-0B1 Motherboard resources
0C0-0DF Direct memory access controller
0F0-0FE Numeric data processor
380-387 ENE CIR Receiver
380-387 Motherboard resources
3B0-3BB ATI Mobility Radeon HD 4650 Series
3B0-3BB PCI Standard PCI-to-PCI Bridge
3C0-3DF ATI Mobility Radeon HD 4650 Series
3C0-3DF PCI Standard PCI-to-PCI Bridge
400-4CF Motherboard resources
4D0-4D1 Motherboard resources
4D6 Motherboard resources
680-6FF Motherboard resources
77A Motherboard resources
C00-C01 Motherboard resources
C14 Motherboard resources
C50-C52 PCI Bus on MS ACPI-Compliant System
C6C Motherboard resources
C6F Motherboard resources
(Continued)
