System information

Product description
Maintenance and Service Guide 1–3
Ethernet Integrated Realtek 10/100/1000 network interface card (NIC) ✔
Integrated Realtek 10/100 NIC ✔
Wireless Integrated wireless local area network (WLAN) options by way of
wireless module:
■ Atheros 9285G 802.11b/g + Bluetooth® with two antennas
■ Broadcom BCM4312 802.11b/g + Bluetooth with two antennas
■ Atheros 9280AGN 802.11a/b/g/n + Bluetooth
■ Broadcom 4322 AGN 802.11a/b/g/draft-n WLAN module (plus
Bluetooth)
■ Intel Wi-Fi Link 5100 802.11a/b/g WLAN module
■ Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module
✔✔
TV Tuner Integrated DVB-T TV tuner (select models only) ✔
Support for TV tuner antennas for both DVB-T and ATSC/NTSC ✔✔
External media card One ExpressCard 54 slot ✔✔
Digital Media Slot supports SD, MMC, MS, MSP, xD. Supports mini
versions of SD, MMC, MS Duo with adapter (purchased separately)
✔✔
Internal card
expansion
Two Mini Card slots
■ One slot for WLAN
■ One slot for TV tuner
Ports VGA, 15-pin supporting 1920 × 1200 resolution at 75Hz ✔
VGA, 15-pin supporting 1600 × 1200 resolution at 75Hz ✔
Hot Plug/Unplug and auto-detect for correct output to wide-aspect vs.
standard-aspect video
✔✔
High-Definition Multimedia Interface (HDMI) v1.3b supporting 1080p
with HDCP key
✔✔
eSATA port combo with fourth USB port ✔✔
Four USB 2.0 ports ✔✔
IEEE 1394a ✔
RJ-11 modem (select models only) ✔✔
RJ-45 Ethernet ✔✔
Consumer infrared ✔✔
MCX connector for TV antennas (select models only) ✔✔
Two stereo headphone jacks (audio-out) ✔✔
Microphone input (audio-in) ✔✔
AC adapter plug ✔✔
Docking Expansion port 3 supports the HP Notebook Expansion Base and HP
Notebook QuickDock
✔✔
Keyboard/pointing
devices
16-inch full-size keyboard with numeric keypad ✔✔
Standard IMR keyboard ✔✔
TouchPad supports 2-way scrolling ✔✔
(Continued)
Category Description
Computers
with discrete
graphics
Computers
with UMA
graphics
