5–4 Maintenance and Service Guide
Setup Utility
System Configuration menu
Diagnostics menu
Select To do this
Language Support Change the Setup Utility language.
Button Sound (select models only) Enable/disable the capacitive button tapping sound.
Virtualization Technology
(select models only)
Enable/disable the processor Virtualization Technology.
Processor C6 State (select models only) Enable/disable the processor C6 sleep state.
LAN Power Saving (select models only) Enable/disable LAN Power Saving. When enabled, saves power when the
computer is in DC mode.
Card Reader/1394 Power Saving
(select models only)
Enable/disable Card Reader/1394 Power Saving.
Fan Always On Enable/disable Fan Always On. When enabled, the computer fan will
always be on.
Boot Options Set the following boot options:
■ f10 and f12 Delay (sec.)—Set the delay for the f9 and f10 functions of the
Setup Utility in intervals of 5 seconds each (0, 5, 10, 15, 20).
■ CD-ROM boot—Enable/disable boot from CD-ROM.
■ Floppy boot—Enable/disable boot from diskette.
■ Internal Network Adapter boot—Enable/disable boot from Internal Network
Adapter.
■ Boot Order—Set the boot order for:
❐ Hard drive
❐ Internal CD/DVD ROM drive
❐ USB Diskette on Key
❐ USB CD/DVD ROM drive
❐ USB Floppy
❐ Network adapter
Select To do this
Hard Disk Self Test Run a comprehensive self-test on the hard drive.
✎
On models with two hard drives, this menu option is called the
Primary Hard Disk Self Test.
Secondary Hard Disk Self Test
(select models only)
Run a comprehensive self-test on a secondary hard drive.
Memory Test Run a diagnostic test on the system memory.
