Table Of Contents
- HP Pavilion dv6 Entertainment PC
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures
- Preliminary replacement requirements
- Component replacement procedures
- Service tag
- Computer feet
- Battery
- Webcam/microphone module
- Optical drive
- Memory module
- TV tuner module
- RTC battery
- Hard drive
- WLAN module
- Switch cover and keyboard
- Power button board
- Bluetooth module
- Display assembly
- Speaker
- Top cover
- Modem module
- Audio/infrared board
- USB board
- Power connector cable
- System board
- TV tuner module cable
- Modem module cable
- Fan/heat sink
- Processor
- Setup Utility
- Specifications
- Computer specifications
- 15.6-inch WXGA display specifications
- Hard drive specifications
- Blu-ray ROM DVD±R/RW SuperMulti DL Drive specification
- DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive specifications
- System DMA specifications
- System interrupt specifications
- System I/O address specifications
- System memory map specifications
- Screw listing
- Backup and Recovery
- Connector pin assignments
- Power cord set requirements
- Recycling
- Index
Maintenance and Service GuideMaintenance and Service Guide 1–1
1
Product description
Category Description
Computers
with discrete
graphics
Computers
with UMA
graphics
Product Name HP Pavilion dv6 Entertainment PC
Processors AMD Turion™ II Ultra Dual-Core Mobile processors:
M640, 2.6-GHz with 2-MB L2 cache ✔✔
M620, 2.5-GHz with 2-MB L2 cache ✔✔
M600, 2.4-GHz with 2-MB L2 cache ✔✔
AMD Turion II Dual-Core Mobile processors:
M520, 2.3-GHz with 1-MB L2 cache ✔✔
M500, 2.2-GHz with 1-MB L2 cache ✔✔
AMD Athlon™ II Dual-Core Processor for Notebook PCs
M320, 2.1-GHz with 1-MB L2 cache ✔✔
M300, 2.0-GHz with 1-MB L2 cache ✔✔
AMD Sempron™ processor:
M100, 2.0-GHz with 512-GB L2 cache ✔✔
Chipset Northbridge: AMD RX881 Chipset ✔
Northbridge: AMD RX880M Chipset ✔
Southbridge: SB710 ✔✔
Graphics ATI Mobility Radeon™ HD 4650 (M96) with 1 GB of dedicated video
memory
✔
ATI Mobility Radeon HD 4530 (M92) with 512 MB of dedicated video
memory
✔
AMD internal graphics with 128-MB SidePort video memory ✔
Unified memory architecture (UMA) with shared video memory (ATI
Radeon HD 4200 graphics):
■ Up to 251 MB for = 1024-MB system RAM
■ Up to 358 MB for > 2048-MB system RAM
■ Memory size changes dynamically
✔
■ Support for BD playback with HD Decode, and DX10 ✔✔
Panel 15.6-inch WXGA (1366 × 768) BrightView LED ✔✔
Support for lighted logo on display enclosure ✔✔
Typical brightness 200 nits ✔✔
(Continued)
