3–18 Maintenance and Service Guide
Illustrated parts catalog
570228-AD1 Black textured keyboard for use in South Korea
570228-BA1 Black textured keyboard for use in Slovenia
570228-DH1 Black textured keyboard for use in the Netherlands
570228-DJ1 Black textured keyboard for use in Greece
570390-001 Display enclosure for use only with white computer models (includes wireless antenna transceivers
and cables and logo LED board and cable)
570391-001 Display enclosure for use only with black computer models (includes wireless antenna transceivers
and cables and logo LED board and cable)
571186-001 System board for use with computers equipped with UMA graphics subsystem memory (includes
replacement thermal material)
571187-001 System board for use with computers equipped with discrete graphics subsystem memory and 1 GB
of dedicated memory (includes replacement thermal material)
571188-001 System board for use with computers equipped with discrete graphics subsystem memory and
512 MB of dedicated memory (includes replacement thermal material)
571742-001 Webcam/microphone module (includes cable)
571747-001 Switch cover for use in white computers (includes LED board and cable)
571757-001 Switch cover for use in black computers (includes LED board and cable)
574554-001 Display cable
574556-001 Display Hinge Kit (includes right and left hinges)
575476-001 500-GB, 7200-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators)
576251-001 AMD Sempron M100, 2.00-GHz processor with 512-KB L2 cache
576252-001 AMD Athlon II Dual-Core M320, 2.10-GHz processor with 1-MB L2 cache
576253-001 AMD Turion II Dual-Core M500, 2.20-GHz processor with 1-MB L2 cache
576254-001 AMD Turion II Ultra Dual-Core M600, 2.40-GHz processor with 2-MB L2 cache
576255-001 AMD Turion II Ultra Dual-Core M620, 2.50-GHz processor with 2-MB L2 cache
576256-001 AMD Turion II Ultra Dual-Core M640, 2.60-GHz processor with 2-MB L2 cache
578024-001 AMD Athlon II Dual-Core M300, 2.00-GHz processor with 1-MB L2 cache
578256-001 15.6-inch WXGA BrightView display assembly for use in black computers (includes webcam, 2
microphones, and 2 antenna transceivers and cables)
578257-001 15.6-inch WXGA BrightView display assembly for use in white computers (includes webcam, 2
microphones, and 2 antenna transceivers and cables)
579159-001 Top cover for use in white computers (includes TouchPad and fingerprint reader)
579160-001 Top cover for use in black computers (includes TouchPad and fingerprint reader)
579161-001 Bluetooth cable
583055-001 AMD Turion II Dual-Core M520, 2.30-GHz processor with 1-MB L2 cache
Spare part number Description
