Illustrated parts catalog
Maintenance and Service Guide 3–17
518966-121 Black painted keyboard for use in French Canada
518966-171 Black painted keyboard for use in Saudi Arabia
518966-201 Black painted keyboard for use in Brazil
518966-281 Black painted keyboard for use in Thailand
518966-AD1 Black painted keyboard for use in South Korea
532139-001 Base enclosure for use in computers with discrete graphics subsystems (includes rubber feet)
532140-001 Base enclosure for use in computers with UMA graphics subsystems (includes rubber feet)
532141-001 Fan/heat sink assembly for use only with computers equipped with graphics subsystems with
discrete graphics memory (includes replacement thermal material)
532142-001 Fan/heat sink assembly for use only with computers equipped with graphics subsystems with UMA
graphics memory (includes replacement thermal material)
533465-001 Power connector cable
533466-001 Cable Kit (see “Cable Kit” on page 3-10)
533865-001 Speaker assembly
537921-001 Bluetooth module for use only with computer models equipped with Intel processors (does not
include a Bluetooth module cable)
✎
The Bluetooth module cable is available using spare part number 579161-001.
570095-001 15.6-in WXGA BrightView display panel (includes display panel cable)
570228-001 Black textured keyboard for use in the United States
570228-031 Black textured keyboard for use in the United Kingdom
570228-041 Black textured keyboard for use in Germany
570228-051 Black textured keyboard for use in France
570228-061 Black textured keyboard for use in Italy
570228-071 Black textured keyboard for use in Spain
570228-111 Black textured keyboard for use in Switzerland
570228-121 Black textured keyboard for use in French Canada
570228-131 Black textured keyboard for use in Portugal
570228-141 Black textured keyboard for use in Turkey
570228-161 Black textured keyboard for use in Latin America
570228-171 Black textured keyboard for use in Saudi Arabia
570228-201 Black textured keyboard for use in Brazil
570228-211 Black textured keyboard for use in Hungary
570228-221 Black textured keyboard for use in the Czech Republic
570228-251 Black textured keyboard for use in Russia
570228-281 Black textured keyboard for use in Thailand
570228-291 Black textured keyboard for use in Japan
570228-B31 Black textured keyboard for use internationally
570228-A41 Black textured keyboard for use in Belgium
570228-AB1 Black textured keyboard for use in Taiwan
(Continued)
Spare part number Description
