3–12 Maintenance and Service Guide
Illustrated parts catalog
Sequential part number listing
Spare part number Description
418162-001 HP carrying case
430958-001 Wireless laser mouse
449729-001 RTC battery
463955-001 90-W AC adapter
463958-001 65-W AC adapter
464793-002 ExpressCard module
465541-001 Full-function remote control with teletext
482899-003 DVB-T TV tuner module
✎
The TV tuner module spare part kit does not include a TV tuner module cable. The TV tuner
module cable is included in the Cable Kit, spare part number 501891-001.
482900-002 TV tuner external antenna cable with PAL jack
483862-001 Hard Drive Hardware Kit (includes left and right bracket rails, connector cable, Mylar cover with tab,
and 4 rubber isolators)
484170-001 6-cell, 47-Wh, 2.20-Ah Li-ion battery
484171-001 6-cell, 55-Wh, 2.50-Ah Li-ion battery
484172-001 12-cell, 95-Wh, 8.8-Ah Li-ion battery
490371-001 Power cord for use in the Asia/Pacific region, French Canada, Latin America, Thailand, and the
United States
490371-011 Power cord for use in Australia and New Zealand
490371-021 Power cord for use in Belgium, Bulgaria, the Czech Republic, Finland, France, Germany, Greece,
Hungary, Iceland, the Netherlands, northwest Africa, Norway, Poland, Portugal, Russia, Slovakia,
Spain, Sweden, and Turkey
490371-031 Power cord for use in the United Kingdom and Hong Kong
490371-061 Power cord for use in Italy
490371-081 Power cord for use in Denmark
490371-111 Power cord for use in Switzerland
490371-202 Power cord for use in Brazil
490371-291 Power cord for use in Japan
490371-AB1 Power cord for use in Taiwan
490371-AD1 Power cord for use in South Korea
490371-AR1 Power cord for use in South Africa
490371-D01 Power cord for use in Argentina
490371-D61 Power cord for use in India
504593-003 Broadcom BCM4312 802.11b/g WLAN module plus Bluetooth plus 2 antennas for use in Antigua
and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and
Tobago, the U.S. Virgin Islands, and the United States
(Continued)
