Illustrated parts catalog
Maintenance and Service Guide 3–11
Miscellaneous parts
Description Spare part number
AC adapters:
90-W AC adapter 463955-001
65-W AC adapter 463958-001
Power cords:
For use in Argentina 490371-D01
For use in Australia and New Zealand 490371-011
For use in Belgium, Bulgaria, the Czech Republic, Finland, France, Germany, Greece,
Hungary, Iceland, the Netherlands, northwest Africa, Norway, Poland, Portugal, Russia,
Slovakia, Spain, Sweden, and Turkey
490371-021
For use in Brazil 490371-202
For use in the Asia/Pacific region, French Canada, Latin America, Thailand, and the United
States
490371-001
For use in India 490371-D61
For use in Israel 490371-BB1
For use in Italy 490371-061
For use in Japan 490371-291
For use in South Africa 490371-AR1
For use in South Korea 490371-AD1
For use in Switzerland 490371-111
For use in Taiwan 490371-AB1
For use in the United Kingdom and Hong Kong 490371-031
HP carrying case 418162-001
Wireless laser mouse 430958-001
Screw Kit
■ Phillips PM2.0x3.0 screws
■ Phillips PM2.0x14.0 captive screws
■ Phillips PM2.5x3.0 screws
■ Phillips PM2.5x4.0 screws
■ Phillips PM2.5x5.0 screws
■ Phillips PM2.5x5.0 captive screws
■ Phillips PM2.5x5.5 captive screws
■ Phillips PM2.5x6.5 screws
■ Phillips PM3.0x3.5 screws
516498-001
