System information

3–6 Maintenance and Service Guide
Illustrated parts catalog
Broadcom 4322 AGN 802.11a/b/g/draft-n WLAN module (plus Bluetooth)
■ For use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam,
Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States
518434-001
■ For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda,
Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain,
Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia,
Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria,
Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad,
Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica,
Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican
Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia,
Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany,
Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau,
Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the
Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia,
Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia,
Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands,
Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro,
Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New
Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua
New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova,
Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia,
Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the
Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and
Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden,
Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia,
Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United
Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia,
and Zimbabwe
518434-002
(16) Audio/infrared board (includes cable) 511892-001
Fan/heat sink assembly (includes replacement thermal material)
(17) For use only with computers equipped with discrete graphics subsystems 532141-001
(18) For use only with computers equipped with UMA graphics subsystems 532142-001
(19) Hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab, and 4
rubber isolators)
500-GB, 7200-rpm 575476-001
500-GB, 5400-rpm 509417-002
320-GB, 7200-rpm (select models only) 509413-002
320-GB, 5400-rpm 509415-002
250-GB, 7200-rpm (select models only) 509412-002
250-GB, 5400-rpm 509414-002
Hard Drive Hardware Kit (not illustrated; includes left and right bracket rails, connector
cable, Mylar cover with tab, and 4 rubber isolators)
483862-001
(20) Base enclosure (includes rubber feet)
For use in computers with discrete graphics subsystems 532139-001
For use in computers with UMA graphics subsystems 532140-001
Rubber Feet Kit (not illustrated, includes 4 base enclosure rubber feet) 516499-001
(Continued)
Item Description Spare Part Number
