System information

2–2 Maintenance and Service Guide
External component identification
Lights
Item Component Description
1
Power lights (2)* ■ On: The computer is on.
■ Blinking: The computer is in the Sleep state.
■ Off: The computer is off or in Hibernation.
2
Battery light ■ On: A battery is charging.
■ Blinking: A battery that is the only available power source has
reached a low battery level. When the battery reaches a critical
battery level, the battery light begins blinking rapidly.
■ Off: If the computer is plugged into an external power source, the
light is turned off when all batteries in the computer are fully
charged. If the computer is not plugged into an external power
source, the light stays off until the battery reaches a low battery
level.
3
Drive light ■ Blinking: The hard drive or optical drive is being accessed.
■ Amber: HP ProtectSmart Hard Drive Protection has temporarily
parked the hard drive.
4
Caps lock light On: Caps lock is on.
5
Volume mute light ■ White: Computer sound is on.
■ Amber: Computer sound is off.
6
Volume down light On: The volume scroll zone is being used to decrease speaker
volume.
7
Volume up light On: The volume scroll zone is being used to increase speaker
volume.
8
Wireless light ■ Blue: An integrated wireless device, such as a wireless local area
network (WLAN) device and/or a Bluetooth® device, is turned on.
■ Amber: All wireless devices are turned off.
9
Num lock light On: The integrated numeric keypad is enabled, or num lock is
enabled on a connected optional numeric keypad.
*The 2 power lights display the same information. The light on the power button is visible only when the computer is open. The
power light on the front of the computer is visible whether the computer is open or closed.
