7–8 Maintenance and Service Guide
Screw listing
Phillips PM2.5×7.0 screw
Where used:
(1) One screw that secures the USB board to the system board
(2) One screw that secures the system board to the computer
(3) One screw that secures the audio/infrared board to the computer
Where used: 4 screws that secure the keyboard to the computer
Color Quantity Length Thread Head diameter
Silver 26 7.0 mm 2.5 5.0 mm
