Rear Components
Z24i Model
Component Function
1 USB 2.0 Downstream
Connectors (side panel)
Connects optional USB devices to the monitor.
2 Master Power Switch Turns off all power to the monitor.
NOTE: Putting the switch in the Off position will yield the
lowest power state for the monitor when not in use.
3 AC Power Connector Connects the AC power cord to the monitor.
4 DisplayPort Connects the DisplayPort cable to the monitor.
5 DVI-D Connects the DVI-D cable to the monitor.
6 VGA Connects the VGA cable to the monitor.
7 USB 2.0 Upstream
Connector
Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub.
8 USB 2.0 Downstream
Connectors
Connects optional USB devices to the monitor.
4 Chapter 2 Setting Up and Using the Monitor
