Toner collection unit
Item Description Part number
Toner Collection Unit Receptacle for waste toner CE254A
For more information, go to www.hp.com/go/learnaboutsupplies.
Replace the toner collection unit
Replace the toner collection unit when the product control panel prompts you.
NOTE: The toner collection unit is designed for a single use. Do not attempt to empty the toner collection
unit and reuse it. Doing so could lead to toner being spilled inside the product, which could result in reduced
print quality. After use, return the toner collection unit to HP’s Planet Partners program for recycling.
NOTE: If printing documents that require heavy toner coverage, the toner collection unit can fill quickly. If
printing these types of documents, HP recommends that you have another toner collection unit available.
1. Open the front door. Make sure that the door is
completely open.
2. Grasp the blue label at the top of the toner
collection unit, and then remove the toner
collection unit from the product.
