CAUTION: Do not use abrasives, acetone, benzene, ammonia, ethyl alcohol, or carbon tetrachloride on
any part of the product; these can damage the product. Do not place liquids directly on the scanner
glass. They might seep and damage the product.
Step 8: Test the fax functionality
1. From the Home screen on the product control panel, touch the Setup button.
2. Open the following menus:
●
Service
●
Fax Service
3. Touch the Run Fax Test button to print the Fax Test Report, which provides information about fax
functionality.
Step 9: Check the toner cartridge
Print a supplies status page and check remaining life of the toner cartridge.
1. From the Home screen on the product control panel, touch the Supplies
button.
2. Touch the Report button to print the supplies status page.
Step 10: Try sending a print job from a computer
1. Try printing the job from another computer that has the product software installed.
2. Check the USB or network cable connection. Direct the product to the correct port, or reinstall the
software, selecting the connection type that you are using.
3. If the print quality is unacceptable, verify that the print settings are correct for the paper that you are
using.
Step 11: Verify that the product is on the network
For networked products, open a Web browser, and enter the product IP address (from the previously printed
configuration page) in the address box to open the HP Embedded Web Server (EWS). If the HP EWS does not
open, reinstall the product on the network.
