Specifications
All specifications represent the typical specifications provided by HP’s component manufacturers; actual
performance may vary either higher or lower.
W220q
Display Type 22 inches, TFT LCD 55.88 cm
Viewable Image Size 22-inch diagonal 55.88 cm
Tilt –5° to 20°
Face Treatment
Antiglare polarizer with hard coating
(select models only)
Maximum Weight (unpacked) 14.551 lb. 6.6 kg
Dimensions (including pedestal)
Height
Depth
Width
17.20 inches
9.84 inches
20.74 inches
437 mm
250 mm
526.7 mm
Optimum Display Resolution 1680 x 1050 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.282 (H) x 0.282 (V) mm
Horizontal Frequency 30 to 81 kHz
Vertical Refresh Rate 56 to 76 Hz
Audio Power Output 2W / channel @ PC 1 Vrms
Speaker (R/L) 2W / 16 ohm speaker
Power Consumption <55 watts typical
Input Terminal VGA connector
Environmental Requirements
Temperature: Operating
Non-operating
41 to 95°F
–4 to 140°F
5 to 35°C
–20 to +60°C
Relative Humidity 20 to 85% (non-condensing)
Power Source 100–240 V, 50–60 Hz
Altitude: Operating
Non-operating
0 to 6,561.68 feet
0 to 40,000 feet
0 to 2,000 m
0 to12,192 m
