Specifications

F Specifications
All-in One Models
Table F-1 Specifications
Desktop Dimensions
Height
Width
Depth
23.00 in
18.58 in
9.06 in
58.4 cm
47.2 cm
23.0 cm
Approximate Weight 18.7 lb 8.5 kg
Display
Resolution
Contrast ratio
Image brightness
Viewing angle (typical)
1920x1080 (16:9)
1000:1 (typical)
250 nits (typical)
Up to 170° horizontal/160° vertical
1920x1080 (16:9)
1000:1 (typical)
250 nits (typical)
Up to 170° horizontal/160° vertical
Temperature Range
Operating
Nonoperating
50° to 95°F
-22° to 149°F
10° to 35°C
-30° to 65°C
Relative Humidity (noncondensing)
Operating
15-80% at 79°F 15-80% at 26°C
Maximum Altitude (unpressurized)
Operating
Nonoperating
0 - 6,562 ft
0 - 15,000 ft
0 - 2000 m
4,572 m
Power Supply
Rated Voltage Range
Rated Line Frequency
100-240 V
50-60 Hz
100-240 V
50-60 Hz
Max Operating Power <180 W <180 W
Idle Operating Power Integrated graphics: 58 W
Discrete graphics: 66 W
Integrated graphics: 58 W
Discrete graphics: 66 W
