Reference Guide

HP Compaq 6000 Pro AIO Illustrated Parts & Service Map 628500-003 page 3
Computer Setup.
Heading Option/Description
File System Information - Lists the following main system specifications:
• Product name
• SKU number (some models)
• Processor type/speed/stepping
• Memory size/speed/ no. channels
• Integrated MAC Address
• System BIOS
• Chassis serial number
• Asset tracking number
• ME firmware version
• Management mode
About - Displays copyright notice.
Set Time and Date - Allows you to set system time and date.
Flash System ROM - Allows you to select a drive containing a new BIOS.
Replicated Setup-Save to Removable Media & Restore from Removable
Media
Default Setup:
• Save Current Settings as Default
• Restore Factory Settings as Default
Apply Defaults and Exit - Applies the selected default settings and clears any
established passwords.
Ignore Changes and Exit - Exits setup without applying or saving any
changes.
Save Changes and Exit - Saves changes to system configuration or default
settings and exits Computer Setup.
Storage Device Configuration - Lists all installed BIOS-controlled storage devices.
• Hard Disk - size, model, firmware, serial number, connector color, SMART,
emulation type
• Emulation type - None, Hard disk
• Translation Mode
Storage Options: Removable Media Boot, SATA Emulation.
DPS Self-Test - Lets you execute self-tests on DPS-capable ATA hard drives.
Boot Order - Allows you to specify boot order or order of attached hard drives.
• Shortcut to Temporarily Override Boot Order
Security Setup Password - Allows you to set and enable setup (Administrator) pass-
word.
Power-On Password - Allows you to set and enable power-on password.
Password Options - When any password exists allows you to lock legacy
resources, enable/disable network server mode, specify password require-
ment for warm boot, and allows you to enable/disable Setup Browse Mode,
enable/disable Stringent Password, set up password prompt on F9, F11, &
F12.
Device Security (some models) - Enables/disables audio, network controllers,
embedded security devices., SATA0-1, 1394 and Media Reader.
USB Security - Allows you to enable/disable groups of or individual USB ports.
Front USB Ports 11,12, Rear USB Ports 1,3,8,9,10. Accessory ports 2,4,6,7.
Slot Security - Allows you to enable/disable any PCI Express x16 or x1 slot.
Network Service Boot - Enables/disables boot from OS on a network server.
System IDs - Allows you to set Asset tag, ownership tag, chassis serial num-
ber/ UUID, and keyboard locale setting.
DriveLock Security-Lets you assign/modify hard drive p/w for added security.
System Security (some models) - Allows you to enable/disable:
• Data Execution Prevention
• Protected Audio Video Path (PAVP) (some models)
• Virtualization Technology(some models)
• Virtualization Technology Directed I/O (some models)
• Trusted Execution Technology I/O
• Embedded Security Device Support
• OS management of Embedded Security Device (some models)
• Button Retask Password Protection
• Power Button
• Consumer IR Power Button
• Optical Drive Eject Button
Master Boot Record Security - Allows you to save or restore master boot
record.
Setup Security Level - Provides method to allow users limited access to
change specified setup options without knowing Setup password.
Power OS Power Management - Lets you enable/disable Runtime Power Manage-
ment, Idle Power Savings, ACPI S3 Hard Disk Reset, ACPI S3 PS2 Mouse
Wakeup, USB Wake on Device Insertion, Unique Sleep State Blink Rates.
Hardware Power Management-Lets you enable/disable SATA bus power man-
agement and S5 maximum power savings.
Thermal - Allows you to control minimum permitted fan idle speed.
Advanced Power-On Options - Allows you to set:
• POST mode-QuickBoot, FullBoot, Clear Memory, FullBoot every x days
• POST messages - Enable/disable
• F9 prompt - Enable/disable
• F10 prompt - Enable/disable
• F11 prompt - Enable/disable
• F12 prompt - Enable/disable
• Factory Recovery Boot Support - Enable/disable
• Option ROM prompt - Enable/disable
• Remote wakeup boot source - Remote server/local hard drive
• After Power Loss - Off/on/previous state
• POST Delay - None, 5, 10, 15, or 20 seconds
• Limit CPUID Value to 3
• Bypass F1 Prompt on Configuration Changes
Execute Memory Test -Restarts computer and executes POST memory test.
BIOS Power-On - Allows you to set the computer to turn on at a preset time.
PCI Devices - Lists installed PCI devices with their IRQ settings and allows
you to reconfigure IRQ or disable devices.
Bus Options (some models) - Allows you to enable/disable PCI SERR# Gen-
eration and PCI VGA palette snooping.
Device Options - Allows you to set:
• Num Lock State at Power-On (on/off)
• S5 Wake on LAN (enable/disable)
• Multi-Processor (enable/disable)
• Internal Speaker (some models)
• NIC Option ROM Download (PXE, Disable, iSCSI
Management Devices - Only displayed in the Advanced Menu when the BIOS
detects multiple management options. This option is for installed NIC cards
that support ASF or DASH. Use the Management Devices menu to select if
the BIOS management operations will be through the embedded solution or
one of the installed NIC cards.
Management Operations - Allows you to set:
• MEBx Setup Prompt (enable/disable)
• Unprovision AMT on next boot.
• SOL Terminal Emulation Mode
• SOL Local Keyboard (enable/disable)
