Media attributes
This section includes the following information about paper attributes:
Paper sources and destinations
Paper-source commands
Driver-supported paper sizes
Driver-supported paper types
Custom paper sizes
Paper-type commands
Paper sources and destinations
The following table indicates the standard and optional paper sources and destinations for the
HP LaserJet P3010 Series product.
Table 6-4 HP LaserJet P3010 Series paper sources and destinations
Paper sources 100-sheet multipurpose tray (tray 1) Standard
250-sheet paper tray (tray 2) Standard
500-sheet paper tray (tray 3) Standard on the HP LaserJet P3015x;
option on all other HP LaserJet P3010
Series models
Paper destinations 50-sheet face-up output bin Standard
250-sheet face-down output bin Standard
Paper-source commands
The PCL 6 Print driver attribute for paper source is ubyte # MediaSource or ubyte_array
"string" MediaSource. See the following table for values of #. For example, "ubyte 4
MediaSource" is the command for Tray 2.
The PCL 5 print driver escape sequence for paper source is Esc&l#H (the "l" is a lowercase "L" rather
than the numeral "1"). See the following table for values of #. For example, Esc&l1H is the command
for Tray 2.
NOTE: The HP LaserJet P3010 Series products support Tray 1, Tray 2, and Tray 3 only.
Table 6-5 Paper-source commands
1
Input source PCL 5
Esc&l#H
PCL 6
ubyte #
MediaSource
2
PCL 6
ubyte_array
"string"
MediaSource
PostScript
/MediaPosition
# or null/
ManualFeed true
or false
Automatically select NA NA NA NA
Printer auto select 7 1 AUTOSELECT null false
