HP LaserJet P3010 Series - Software Technical Reference
Table Of Contents
- Purpose and scope
- Introduction
- Product comparison
- Product features
- Quick Reference Job Aids
- Product views
- Printing-system software
- Operating-system support
- Supported operating systems for Windows
- Supported printer drivers for Windows
- HP Universal Print Driver (UPD)
- Supported utilities for Windows
- Supported operating systems for Macintosh
- Supported printer drivers for Macintosh
- Supported utilities for Macintosh
- Software for other operating systems
- Printer driver support in other operating systems
- Availability
- Operating-system support
- Documentation availability and localization
- Software description
- Windows printing-system software
- Supported operating systems for Windows
- Windows system requirements
- Macintosh system requirements
- Printer driver
- Select the correct printer driver for Windows
- Priority for print settings
- Change printer-driver settings for Windows
- Printing system and installer
- Driver version numbers for Windows operating systems
- Windows printer-driver configuration
- HP Driver Diagnostic Printer Check Tool
- Embedded Web Server
- HP Web Jetadmin
- Font support
- Windows printing-system software
- Install Windows printing-system components
- Supported operating systems for Windows
- Windows operating system requirements
- Install overview
- Software installation types for Windows
- Installation options
- Microsoft Windows general installation overview
- HP LaserJet P3010 Series printing-system software CD for Windows systems
- Microsoft Windows installation for direct connections (Plug and Play)
- Install the print driver using the Microsoft Add Printer Wizard
- Microsoft Windows installation for computers on a network
- Point and Print installation for Windows 2000 Service Pack 3, XP, Server 2003, Server 2008, and Vist ...
- Detailed MS Windows installation instructions
- Install documentation and optional software
- Uninstall software
- HP PCL 6 Print Driver for Windows
- Introduction
- Gain access to print drivers
- Help system
- Advanced tab features
- Printing Shortcuts tab features
- Paper/Quality tab features
- Effects tab features
- Finishing tab features
- Job Storage tab features
- Services tab features
- Device Settings tab features
- About tab features
- Macintosh software and utilities
- Supported operating systems for Macintosh
- Macintosh system requirements
- Macintosh printing-system software
- Macintosh install and uninstall instructions
- HP Printer Utility for Macintosh
- Use features in the Macintosh printer driver
- Engineering Details
- Introduction
- Remote firmware update
- Determining the current level of firmware
- Downloading the new firmware from the HP Web site
- Downloading the new firmware to the product
- Printer messages during the firmware update
- Remote firmware update by using FTP through a browser
- Remote firmware update by using FTP on a direct network connection
- Remote firmware update through a local Windows port
- Remote firmware update through a USB port
- Remote firmware update through a Windows network
- Remote firmware update for UNIX systems
- Remote firmware update by using the LPR command
- HP Easy Firmware Upgrade utility
- Printing print-ready documents
- Print-ready file printing by using FTP through a browser
- Print-ready file printing by using FTP on a direct network connection
- Print-ready printing by using a local Windows port
- Print-ready file printing in a Windows network
- Print-ready file printing in UNIX systems
- Print-ready file printing by using the LPR command
- Media attributes
- Index
Three messages appear during a normal update process; a fourth (RESEND UPGRADE) appears only
if the update process does not succeed.
Table 6-3 Update messages
Printer message Explanation
RECEIVING UPGRADE This message appears from the time the product recognizes the beginning of
an .RFU update until the time the product has verified the validity and integrity of
the .RFU update.
NOTE: If the remote firmware update process is interrupted before the firmware
is downloaded (while RECEIVING UPGRADE appears on the control-panel
display), the firmware file must be sent again. No message appears on the product
control panel to indicate that the update was interrupted.
PERFORMING UPGRADE This message appears while the product is actually reprogramming the firmware.
NOTE: If power is lost during the flash DIMM update (while PERFORMING
UPGRADE appears on the control-panel display), the update is interrupted and
the message RESEND UPGRADE appears on the control-panel display.
INITIALIZING This message appears from the time the product has finished reprogramming the
DIMM until the product reinitializes.
RESEND UPGRADE This message appears (in English only) if the firmware update fails because the
RFU process is interrupted. It can also occur if firmware for accessories (such as
the duplex unit or an output device fails to update. Perform another update by any
means that is supported by the product, regardless of the connection (network,
parallel, or USB).
RFU LOAD ERROR
SEND RFU UPGRADE
ON <X> PORT
where X = Network or USB
This message appears (in English only) if the firmware update fails because the
print-engine firmware is corrupted.
NOTE: When this message appears, the firmware upgrade must be sent twice
to upgrade all firmware components, even though the product returns to ready
after the first upgrade.
DOWNLOAD FILE NOW
SEND RFU UPGRADE
MISMATCH BETWEEN
PRODUCT AND FILE
The wrong firmware file was sent to the product. Send the correct firmware file.
NOTE: To verify that the firmware update succeeded, print a new configuration page from the control
panel and verify that the firmware date code on the configuration page has changed.
NOTE: If the product exhibits unexpected behavior after correcting a firmware update, turn the power
off, and then back on.
Remote firmware update by using FTP through a browser
Complete the following steps to update the product firmware by using file transfer protocol (FTP) through
a browser.
