HP LaserJet M9040/M9050 MFP - User Guide

Menu item Sub-menu item Sub-menu item Values Description
Fax Send Settings Fax Dial Volume Off
Low (default)
High
Use this feature to set the volume of the tones
that you hear while the device dials the fax
number.
Error Correction
Mode
Enabled (default)
Disabled
When Error Correction Mode is enabled and
an error occurs during fax transmission, the
device sends or receives the error portion
again.
JBIG Compression Enabled (default)
Disabled
JBIG compression reduces fax-transmission
time, which can result in lower phone
charges. However, using JBIG compression
sometimes causes compatibility problems
with older fax machines. If this occurs, turn off
JBIG compression.
Maximum Baud Rate Select a value from
the list. The default is
33.6K.
Use this feature to set the maximum baud
rate for receiving faxes. This can be used as
a diagnostic tool for troubleshooting fax
problems.
TCF T.30 Delay
Timer
Default (default)
Custom
This setting should be left at the default value
and only changed when directed by an HP
technical support agent. Adjustment
procedures associated with this setting are
beyond the scope of this guide.
TCF Extend Default (default)
Custom
This setting should be left at the default value
and only changed when directed by an HP
technical support agent. Adjustment
procedures associated with this setting are
beyond the scope of this guide.
Dialing Mode Tone (default)
Pulse
Select whether the device should use tone or
pulse dialing.
Redial On Busy The range is between
0 and 9. The factory
default is 3 times.
Type the number of times the device should
attempt to redial if the line is busy.
Redial On No Answer Never (default)
Once
Twice
Use this feature to specify the number of
times the device should attempt to dial if the
recipient fax number does not answer.
NOTE: Twice is available in locations other
than the United States and Canada.
Table 2-11 Fax Setup menu (continued)
ENWW Use the Administration menu 35
