Tell Me About the Icons on the Front Panel
...continued on next page...
These six icons refer to the amount of ink in each of
the ink cartridges. Flashing: Ink cartridge needs
to be replaced.
(In the case of a hardware error, ink level
information is replaced with diagnostic
information.)
A flashing printhead icon (at the bottom)
indicates a printhead failure or the printer cannot
detect a printhead. Action: Check that the
printhead was inserted correctly, and that the
connections are clean. If necessary, replace the
printhead.
Flashing: Printing, cancelling job, drying, powering
off. The icon flickers if the top or side cover is open.
Action: Close the top cover or close the side cover.
When off: Printer is powered off, idle or awaiting
user action.
Flashing: Out of paper or printer cannot load
paper from source. Action: Check paper source,
add paper and press OK key.
Flashing: Printer waiting. Action: Press the OK key.
When off: Normal.
Flashing: The paper is misaligned and must be
reloaded to print. Action: Reload the paper. When
off: Normal.
