C SAN Switch technical specifications

This appendix provides the following information:

• General specifications, page 51

• Weight and physical dimensions, page 52

• Environmental requirements, page 53

• Supported SFPs, page 53

• Supported HBAs, page 53

General specifications

Table 18 lists general specifications for the 8Gb SAN Switch for HP BladeSystem c-Class.

Table 18 General specifications

DescriptionSpecification

F_Port, FL_Port, and E_Port

Configurable port types

Small Form-Factor Pluggable (SFP) laser. 1/2/4/8Gb short

wave up to 500 m (1,640 ft.) and 1/2/4/8Gb long wave

up to 10 km

Note: 4Gb SFPs support 1/2/4 Gbps, and the 8Gb SFPs

support 2/4/8 Gbps.

Media types

An operating SAN Switch conforms to the emissions

requirements specified by the following regulations:

• FCC Rules and Regulations, Part 15 subpart B, Class A

• CSA C108.8 Class A

• VCCI Class A ITE

• CISPR 22 Class A

• EN55022 Class A

• AS/NZF 3548: 1995 Class A

• CNS13438 Class A

• ICES-003 Class A

• Korean EMC Requirements

• BSMI Standard CNS 13438

• EMC Directive 89/336/EEC

• EN5022 Level A

• EN50082-2/EN55024: 1998

EMC emissions
