Brocade 8Gb SAN Switch for HP BladeSystem c-Class user guide (5697-0960, May 2011)

The gateway address of the first switch should be set to whatever the gateway address is for the
subnet on which the first switch resides. See Table 12.
Table 12 Connecting with a management station
Third switchSecond switchFirst switchManagement station
204.1.1.12204.1.1.11192.168.1.10192.168.1.09Ethernet
192.168.65.12192.168.65.11192.168.65.10192.168.65.09FCIP
192.168.1.10192.168.1.10any, not self192.168.1.10Gateway
Maintaining the 8Gb SAN Switch
The 8Gb SAN Switch does not require any regular physical maintenance.
However, it is critical that environmental conditions, described in Environmental requirements, page 53,
are met to help prevent switch failure due to heat stress or improper air flow.
Installing dust covers in empty ports
The dust covers included in the 8Gb SAN Switch shipping carton (see Figure 1) must be inserted in
ports where SFPs are not installed. Installing dust covers ensures proper air flow and helps reduce
dust contamination of the switch.
Replacing an SFP transceiver
In some cases, you might need to reinstall an SFP transceiver.
To remove an SFP transceiver:
1. Press and hold the cable release.
2. Remove the cable from the transceiver.
3. Pull the bail (wire handle) to release the transceiver.
4. Grasp the bail, and gently but firmly pull the transceiver out of the port.
5. Repeat this procedure for the remaining ports as required.
To install a replacement SFP:
1. Make sure that the bail is in the unlocked position.
Managing the 8Gb SAN Switch34
