2 Get to Know the HP Photosmart
• Printer parts
•
Control panel features
•
Tips for getting to know the printer
Printer parts
• Front view of the printer
1Lid
2 Lid Backing
3Glass
4 Color graphics display (also referred to as the display)
5 Memory Card slots LED
6 Memory Card slots
7 USB Drive slot
8 Photo tray
9 Paper-width guide for the photo tray
10 Paper tray extender (also referred to as the tray extender)
11 Paper-width guide for the main tray
12 Main tray (also referred to as the input tray)
13 Output tray
14 Wireless LED
15 On button
16 Cartridge door
17 Automatic document feeder
18 Automatic document feeder tray
• Top and rear views of the printer
