User's Manual
Table Of Contents
- Locating HP resources
- Computer features
- Setting up the computer
- Backing up, restoring, and recovering
- Using Windows tools
- Creating HP Recovery media (select products only)
- Restoring and recovery
- Restoring, resetting, and refreshing using Windows tools
- Restoring using HP Recovery Manager and the HP Recovery partition
- Recovering using HP Recovery Manager
- Recovering using the HP Recovery partition (select products only)
- Recovering using HP Recovery media
- Changing the computer boot order
- Removing the HP Recovery partition (select products only)
- Setting up Linux
- Updating the computer
- Maintenance, diagnostics, and minor troubleshooting
- Using HP PC Hardware Diagnostics
- Routine care
- Accessibility
- Index
Item Icon Component Item Icon Component
3 Audio-in (microphone) jack 10 Security cable slot
4 PS/2 mouse port 11 Security lock loop
5 PS/2 keyboard port 12 RJ-45 (network) jack
6 USB SuperSpeed ports (5) 13 PCIe card release latches
7 Cable-only slot 14 PCIe card slots (5)
* The power light status is as follows:
● Solid white: The computer is on.
● Blinking white: The computer is in the Sleep state, a power-saving state. The computer shuts o power to the display and other
unneeded components.
● Blinking red: The computer is in a fault state. For additional information, see the computer Maintenance and Service Guide at
http://www.hp.com/support.
● O: The computer is o or in Hibernation. Hibernation is a power-saving state that uses the least amount of power.
Product specications
To nd the QuickSpecs for your product, go to http://www.hp.com/go/quickspecs. Click the link for the HP Inc.
QuickSpecs experience. Click Search all QuickSpecs, type your model name in the search eld, and then click
Go.
– or –
Go to http://www.hp.com/support, and follow the instructions to nd your product. Select Product
Information, and then select your workstation specications.
8 Chapter 2 Computer features
