Data Sheet

Data sheet | HP EliteBook 840 G6 Notebook PC
HP recommends Windows 10 Pro.
HP EliteBook 840 G6 Notebook PC Specifications TableHP EliteBook 840 G6 Notebook PC Specifications Table
AAAvvvaaaiiilllaaabbbllleee OOOpppeeerrraaatttiiinnnggg SSSyyysssttteeemmmsss
Windows 10 Pro 64
Windows 10 Pro 64 (National Academic only)
Windows 10 Home 64 – HP recommends Windows 10 Pro.
Windows 10 Home Single Language 64
Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)
FreeDOS
PPPrrroooccceeessssssooorrr fffaaammmiiilllyyy
8th Generation Intel® Core™ i7 processor (i7-8565U); 8th Generation Intel® Core™ i5 processor (i5-8265U); 8th Generation Intel® Core™ i7
processor (i7-8665U); 8th Generation Intel® Core™ i5 processor (i5-8365U)
AAAvvvaaaiiilllaaabbbllleee PPPrrroooccceeessssssooorrrsss
Intel® Core™ i7-8565U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4
c o r e s )
Intel® Core™ i5-8265U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4
c o r e s )
Intel® Core™ i7 8665U vPro™ processor with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology,
8 MB L3 cache, 4 cores)
Intel® Core™ i5 8365U vPro™ processor with Intel® UHD Graphics 620 Graphics (1.6 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost
Technology, 6 MB L3 cache, 4 cores)
MMMaaaxxxiiimmmuuummm mmmeeemmmooorrryyy
32 GB DDR4-2400 SDRAM
Both slots are customer accessible/upgradeable. Supports dual channel memory.
MMMeeemmmooorrryyy sssllloootttsss 2 SODIMM
IIInnnttteeerrrnnnaaalll ssstttooorrraaagggeee
256 GB up to 2 TB PCIe® NVMe™ M.2 SSD
512 GB PCIe® NVMe™ M.2 SSD
512 GB M.2 SATA FIPS 140-2 SSD
512 GB PCIe® NVMe™ M.2 SED SSD
256 GB M.2 SATA SED SSD
128 GB M.2 SATA SSD
SSStttooorrraaagggeee aaacccccceeellleeerrraaatttiiiooonnn 32 GB PCIe® NVMe™ Intel® Optane™ Memory for storage acceleration
DDDiiisssppplllaaayyy
14" diagonal UHD IPS anti-glare WLED-backlit, 400 nits, 72% NTSC (3840 x 2160)
14" diagonal FHD IPS eDP anti-glare WLED-backlit slim, 250 nits, 45% NTSC (1920 x 1080)
14" diagonal FHD IPS eDP + PSR anti-glare WLED-backlit ultraslim, 400 nits, 72% NTSC (1920 x 1080)
14" diagonal FHD IPS eDP BrightView WLED-backlit slim touch screen, 250 nits, 45% NTSC (1920 x 1080)
AAAvvvaaaiiilllaaabbbllleee GGGrrraaappphhhiiicccsss
Integrated: Intel® UHD Graphics 620
Discrete: AMD Radeon™ RX 550 (up to 2 GB GDDR5 of dedicated video memory)
(Support HD Decode, DX12, and HDMI 1.4b.)
AAAuuudddiiiooo Bang & Olufsen, dual stereo speakers, 3 multi array microphone
WWWiiirrreeellleeessssss ttteeeccchhhnnnooolllooogggiiieeesss
Intel® XMM™ 7560 LTE-Advanced Pro Cat 16
Intel® XMM™ 7360 LTE-Advanced Cat 9
Intel® XMM™ 7262 LTE-Advanced Cat 6
Intel® AX200 Wi-Fi 6 (2x2) and Bluetooth® 5 Combo, vPro™
Intel® AX200 Wi-Fi 6 (2x2) and Bluetooth® 5 Combo, non-vPro™
(Compatible with Miracast-certified devices.)
PPPooorrrtttsss aaannnddd CCCooonnnnnneeeccctttooorrrsss
2 USB 3.1 Gen 1 (charging); 1 Thunderbolt™ (USB Type-C™ connector); 1 RJ-45; 1 headphone/microphone combo; 1 HDMI 1.4b; 1 docking
connector; 1 AC power
(Cables are not included.)
IIInnnpppuuuttt dddeeevvviiiccceeesss
HP Premium Collaboration Keyboard, spill resistant with drain, optional backlit keyboard and DuraKeys ; Clickpad with multi-touch gesture
support, taps enabled as default; Precision Touchpad with multi-touch gesture support ; Ambient light sensor
CCCooommmmmmuuunnniiicccaaatttiiiooonnnsss
HP Module with NXP NFC Controller NPC300 I2C NCI
Intel® I219-LM GbE, vPro™
Intel® I219-V GbE, non-vPro™ ;
CCCaaammmeeerrraaa 720p HD camera; HD IR webcam
AAAvvvaaaiiilllaaabbbllleee SSSoooffftttwwwaaarrreee
HP Connection Optimizer; HP Hotkey Support; HP Image Assistant; HP JumpStart; HP Noise Cancellation Software; HP Support Assistant; Native
Miracast support; Buy Office (Sold separately)
SSSeeecccuuurrriiitttyyy
mmmaaannnaaagggeeemmmeeennnttt
Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Fingerprint Sensor; Power-on authentication; Preboot authentication;
TPM 2.0 embedded security chip shipped with Windows 10 (Common Criteria EAL4+ Certified); HP Sure Click; Windows Defender; HP Sure Start
Gen5; HP Sure Run Gen2; HP Sure Recover Gen2; HP BIOSphere Gen5; HP Client Security Gen5; HP Sure Sense
MMMaaannnaaagggeeemmmeeennnttt fffeeeaaatttuuurrreeesss HP Driver Packs; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client Catalog; HP Manageability Integration Kit Gen3
PPPooowwweeerrr
HP Smart 65 W External AC power adapter; HP Smart 65 W EM External AC power adapter; HP Smart 65 W USB Type-C™ adapter; HP Smart 45 W
External AC power adapter; HP Smart 45 W USB Type-C™ adapter; HP Smart 45 W 2-prong External AC power adapterHP Smart 65 W External AC
power adapter; HP Smart 65 W EM External AC power adapter; HP Smart 65 W USB Type-C™ adapter; HP Smart 45 W External AC power adapter;
HP Smart 45 W USB Type-C™ adapter; HP Smart 45 W 2-prong External AC power adapter
BBBaaatttttteeerrryyy tttyyypppeee HP Long Life 3-cell, 50 Wh Li-ion
DDDiiimmmeeennnsssiiiooonnnsss 12.84 x 9.22 x 0.71 in
WWWeeeiiiggghhhttt Starting at 3.27 lb
EEEnnneeerrrgggyyy eeeffffffiiiccciiieeennncccyyy cccooommmpppllliiiaaannnccceee ENERGY STAR® 7.0 certified; EPEAT® 2019 Gold
EEEnnnvvviiirrrooonnnmmmeeennntttaaalll ssspppeeeccciiifffiiicccaaatttiiiooonnnsss Low halogen; TCO 8.0 Certified
WWWaaarrrrrraaannntttyyy
HP Services offers 3-year and 1-year limited warranties and 90 day software limited warranty options depending on country. Batteries have a
default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. Refer to
http://www.hp.com/support/batterywarranty/ for additional battery information. On-site service and extended coverage is also available. HP Care
Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your
HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.
