Datasheet | HP Z8 G4 Workstation

HP recommends Windows 10 Pro.

HP Z8 G4 Workstation Specifications Table

Operating System Windows 10 Pro for Workstations

1, 21, 22

HP Installer Kit for Linux®

HP Red Hat® Enterprise Linux®

(HP Linux®Installer Kit includes drivers for 64-bit versions of Red Hat® Enterprise Linux®6.7 and 7, SUSE Linux®Enterprise Desktop 11 and Ubuntu 14.04. Red

Hat®Enterprise Linux®(1-year paper license only) is available as a second operating system.)

Processor Family Intel® Xeon® Scalable processor

Processors

2,3

Intel® Xeon® Platinum 8180 (2.5 GHz base frequency, up to 3.8 GHz with Intel® Turbo Boost Technology, 38.5 MB cache, 28 cores)

Intel® Xeon® Platinum 8160 (2.1 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 33 MB cache, 24 cores)

Intel® Xeon® Gold 6152 (2.1 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 30.25 MB cache, 22 cores)

Intel® Xeon® Gold 6154 (3 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 24.75 MB cache, 18 cores)

Intel® Xeon® Gold 6148 (2.4 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 27.5 MB cache, 20 cores)

Intel® Xeon® Gold 6142 (2.6 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 22 MB cache, 16 cores)

Intel® Xeon® Gold 6136 (3 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 24.75 MB cache, 12 cores)

Intel® Xeon® Gold 6140 (2.3 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 24.75 MB cache, 18 cores)

Intel® Xeon® Gold 6134 (3.2 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 24.75 MB cache, 8 cores)

Intel® Xeon® Gold 6132 (2.6 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 19.25 MB cache, 14 cores)

Intel® Xeon® Gold 6130 (2.1 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 22 MB cache, 16 cores)

Intel® Xeon® Gold 6128 (3.4 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 19.25 MB cache, 6 cores)

Intel® Xeon® Gold 5120 (2.2 GHz base frequency, up to 3.2 GHz with Intel® Turbo Boost Technology, 19.25 MB cache, 14 cores)

Intel® Xeon® Gold 5118 (2.3 GHz base frequency, up to 3.2 GHz with Intel® Turbo Boost Technology, 16.5 MB cache, 12 cores)

Intel® Xeon® Gold 5122 (3.6 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology, 16.5 MB cache, 4 cores)

Intel® Xeon® Silver 4116 (2.1 GHz base frequency, up to 3 GHz with Intel® Turbo Boost Technology, 16.5 MB cache, 12 cores)

Intel® Xeon® Silver 4114 (2.2 GHz base frequency, up to 3 GHz with Intel® Turbo Boost Technology, 13.75 MB cache, 10 cores)

Intel® Xeon® Silver 4112 (2.6 GHz base frequency, up to 3 GHz with Intel® Turbo Boost Technology, 8.25 MB cache, 4 cores)

Intel® Xeon® Silver 4108 (1.8 GHz base frequency, up to 3 GHz with Intel® Turbo Boost Technology, 11 MB cache, 8 cores)

Intel® Xeon® Bronze 3106 (1.7 GHz, 11 MB cache, 8 cores)

Intel® Xeon® Bronze 3104 (1.7 GHz, 8.25 MB cache, 6 cores)

Chipset Intel® C622

Maximum Memory 3 TB DDR4-2666 ECC SDRAM

(Transfer rates up to 2666 MT/s.)

Memory Slots 24 DIMM

Drive Controllers Integrated SATA 6.0 Gb/s; Factory integrated RAID available for SATA/SAS drives (RAID 0, 0 Data, 1, 5, and 10)

Internal Storage 300 GB SAS (15000 rpm)

500 GB up to 2 TB SATA (7200 rpm)

500 GB SATA SED (7200 rpm)

1 TB up to 4 TB 7200 rpm SATA Enterprise

256 GB up to 2 TB SATA SSD

256 GB up to 512 GB SATA SED Opal 2 SSD

240 GB up to 480 GB SATA Enterprise SSD

256 GB up to 1 TB HP Z Turbo Drive PCIe® SSD M.2

256 GB up to 512 GB HP Z Turbo Drive PCIe® SED SSD M.2

256 GB up to 4 TB HP Z Turbo Drive Quad Pro PCIe® SSD

Optical Storage HP Slim DVD-ROM; HP Slim Blu-ray Writer; HP Slim DVD-Writer

5,6

Additional Storage HP SD 4 Media Card Reader (optional)

Available Graphics Entry 3D: NVIDIA® Quadro® P400 (2 GB GDDR5 dedicated); NVIDIA® Quadro® P600 (2 GB GDDR5 dedicated); AMD FirePro™ W2100 Graphics (2 GB

DDR3 dedicated)

Mid-range 3D: NVIDIA® Quadro® P1000 (4 GB GDDR5 dedicated); NVIDIA® Quadro® P2000 (5 GB GDDR5 dedicated); AMD Radeon™ Pro WX 3100

Graphics (4 GB GDDR5 dedicated); AMD Radeon™ Pro WX 4100 Graphics (4 GB GDDR5 dedicated)

High-end 3D: NVIDIA® Quadro® P4000 (8 GB GDDR5 dedicated); AMD Radeon™ Pro WX 7100 Graphics (8 GB GDDR5 dedicated)

Ultra High-end 3D: NVIDIA® Quadro® P5000 (16 GB GDDR5X dedicated); NVIDIA® Quadro® P6000 (24 GB GDDR5X dedicated); AMD Radeon™ Pro

WX 9100 Graphics (16 GB HBM2 dedicated); NVIDIA® Quadro® GP100 (16 GB HBM2 dedicated)

7,20

Audio Realtek HD ALC221

Networking LAN: Integrated Intel® I219-LM PCIe® GbE; Integrated Intel® X722 PCIe® GbE; Intel® I350-T2 dual-port GbE NIC; Intel® I350-T4 dual-port GbE NIC;

Intel® I210-T1 PCIe® GbE; Intel® X550-T2 dual-port GbE NIC; Intel® X710-DA2 dual-port GbE NIC; Intel® 10 GbE SFP+ SR transceiver; HP dual-port

10GBase-T NIC

WLAN: Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo, non-vPro™

Expansion Slots 2 PCIe x4; 3 PCIe x8; 4 PCIe x16

(1 PCIe x8 has rear bulkhead access and 2 PCIe x8 are internal access only. Slot 1: Transforms to PCIe x8 when 2nd CPU is installed. Slots 3 and 6: are available only when

2nd processor is installed. PCIe x16 - Available only when 2nd processor is installed.)

Ports and Connectors Front: 1 headset connector; 4 USB 3.1 (1 charging); 2 USB 3.1 Type-C™

Rear: 1 PS/2 keyboard port; 1 PS/2 mouse port; 2 RJ-45 (1 GbE); 6 USB 3.1 Gen 1; 1 audio-in; 1 audio-out; 1 serial

(Premium front includes: 1 headset, 2 USB 3.1 Gen1 (1 charging), 2 USB 3.1 Gen 2 Type-C™, SD Media Card Reader.)
