Data Sheet

Datasheet | HP ZBook x2 G4 Detachable Workstation
HP recommends Windows 10 Pro.
HP ZBook x2 G4 Detachable Workstation Specifications Table
Operating System
Windows 10 Pro for Workstations 64 – HP recommends Windows 10 Pro.
1
Windows 10 Pro for Workstations
1
Windows 10 Home Single Language 64
1
FreeDOS 2.0
Processor Family 7th Generation Intel® Core™ i7 processor (i7-7500U, i7-7600U); 8th Generation Intel® Core™ i7 processor (i7-8650U, i7-8550U); 8th Generation
Intel® Core™ i5 processor
2,3,25
Processors
2,3,25
Intel® Core™ i7-7500U with Intel® HD Graphics 620
(2.7 GHz base frequency, up to 3.5 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
Intel® Core™ i7-7600U with Intel® HD Graphics 620 (2.8 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
Intel® Core™ i5-8250U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.4 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores)
Intel® Core™ i7-8550U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)
Intel® Core™ i7-8650U with Intel® UHD Graphics 620 (1.9 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)
Maximum Memory 32 GB DDR4-2133 non-ECC SDRAM
(Transfer rates up to 2133 MT/s)
Memory Slots 2 SODIMM
Internal Storage 128 GB M.2 SATA SSD
4
512 GB M.2 SATA FIPS SSD
4
256 GB up to 512 GB HP Z Turbo Drive PCIe® NVMe™ SSD
4
256 GB up to 2 TB PCIe® NVMe™ M.2 SSD
4
512 GB PCIe® NVMe™ M.2 SED SSD
4
Available Graphics Integrated: Intel® HD Graphics 620; Intel® UHD Graphics 620
6
Discrete: NVIDIA® Quadro® M620 (2 GB GDDR5 dedicated)
Networking WLAN: HP hs3110 HSPA+ Intel® Mobile Broadband Module; Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2
Combo
5
Expansion Slots 1 smart card reader; 1 SD media card reader
(SD supports next generation secure digital and is backward compatible to SDHC, SDXC)
Display 14" diagonal 4K IPS anti-glare (3840 x 2160)
HP DreamColor 14" diagonal 4K IPS anti-glare touch screen (3840 x 2160)
Ports and Connectors Left side: 1 headphone/microphone combo
Right side: 1 power connector; 1 HDMI 1.4; 1 USB 3.0 (charging); 2 USB 3.1 Type-C™ Thunderbolt™ 3 (DisplayPort™ 1.2)
Input Device Backlit keyboard with function key control
Image sensor clickpad with on/off button, two-way scroll, gestures, two buttons; Extra large clickpad with on/off button, two-way scroll,
gestures, two buttons
Camera
720p HP webcam (front-facing); 720p HD webcam with IR (front-facing); 8 MP (world-facing camera)
7,8
Software HP Mobile Workstations are shipped with a variety of software titles including: HP Performance Advisor, HP Remote Graphics Software, HP Client
Security, HP Drive Encryption (FIPS 140-2), Microsoft Security Essentials, Microsoft Defender, HP ePrint Driver, HP PageLift. Please refer to this
product's quick spec document for a full list of preinstalled software.
9,10,18
Security Absolute Persistence Module; DriveLock and Automatic DriveLock; HP Spare Key; RAID (available as a configurable option); Serial, parallel, USB
enable/disable (via BIOS); Setup password (via BIOS); Power-on password (via BIOS); HP Client Security Suite Gen 3; HP Security Manager; HP
Credential Manager; HP Password Manager; HP Power On Authentication; HP Device Access Manager; Trusted Platform Module TPM 2.0
Embedded Security Chip; Support for chassis padlocks and cable lock devices; Integrated hood sensor
11,12,13,14,19,24
Management Features HP Driver Packs; HP SoftPaq Download Manager (SDM) preinstalled; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client
Catalog; HP Management Integration Kit for Microsoft System Center Configuration Manager; LANDESK Management
20,21,22
Power 90 W external AC power adapter; 65 W external AC power adapter
15
HP Long Life 4-cell, 70 Wh Li-ion polymer Up to 10 hours
23
Dimensions (W x D x H) 14.35 x 8.94 x .8 in (laptop mode); 14.35 x 8.94 x .57 in (tablet mode)
36.45 x 22.7 x 2.03 cm (laptop mode); 36.45 x 22.7 x 1.46 cm (tablet mode)
Weight Starting at 4.78 lb (laptop mode); Starting at 3.64 lb (tablet mode)
Starting at 2.17 kg (laptop mode); Starting at 1.65 kg (tablet mode)
Energy Efficiency Compliance ENERGY STAR® certified and EPEAT® registered configurations available
16
Environmental Certification Low halogen
17
Warranty 3 year or 1 year limited warranty options available, depending on country. Batteries have the same 1 year or 3 year limited warranty as the
platform. 24/7 operation will not void the HP warranty. Optional HP Care Pack Services are extended service contracts which go beyond your
standard limited warranties.
2
