Replace the toner-collection unit
Replace the toner-collection unit if you receive a message on the printer, or if you have print quality problems.
●
Toner-collection unit information
●
Remove and replace the toner-collection unit
Toner-collection unit information
Replace the toner-collection unit when the control panel prompts you.
Table 3-10 Toner-collection unit information
Item Description Cartridge number Part number
HP Toner Collection Unit Replacement toner-collection unit Not applicable 3WT90A
CAUTION: When the toner-collection unit reaches the end of its life, the printer will stop printing to avoid
damage to internal parts. You must replace the toner-collection unit to continue printing.
NOTE: The toner-collection unit is designed for a single use. Do not attempt to empty the toner-collection unit
and reuse it. Doing so could lead to toner being spilled inside the printer, which could result in reduced print
quality. After use, return the toner-collection unit to HP’s Planet Partners program for recycling.
CAUTION: If toner gets on clothing, wipe it o by using a dry cloth and wash the clothes in cold water. Hot water
sets toner into fabric.
Remove and replace the toner-collection unit
Follow these steps to replace the toner-collection unit.
1. Open the front door.
ENWW Replace the toner-collection unit 81
