Replace the imaging drums
Replace an imaging drum if you receive a message on the printer, or if you have print quality problems.
●
Imaging drum information
●
Remove and replace the imaging drums
Imaging drum information
This printer indicates when an imaging drum level is low and very low. The actual imaging drum life remaining
can vary. Consider having a replacement imaging drum available to install when print quality is no longer
acceptable.
To purchase imaging drums or check imaging drum compatibility for the printer, go to HP SureSupply at
www.hp.com/go/suresupply. Scroll to the bottom of the page and verify that the country/region is correct.
The printer uses four imaging drums installed next to each toner cartridge. One universal imaging drum part ts
in all four positions. The imaging drums are inside the front door.
Table 3-9 Imaging drum information
Item Description Cartridge number Part number
HP Imaging Drum Replacement imaging drum 660A W2004A
Do not remove the imaging drum from its package until it is time to replace it.
CAUTION: To prevent damage to the imaging drum, do not expose it to light for more than a few minutes. Cover
the green imaging drum if it must be removed from the printer for an extended period of time. Do not touch the
imaging drum. Fingerprints on the imaging drum can cause print-quality problems.
The following illustration shows the imaging drum components.
1
2
4
3
Number Description
1 Handle
2 Imaging drum
