Replace the toner cartridges
Replace the toner cartridge if you receive a message on the printer, or if you have print quality problems.
●
Toner-cartridge information
●
Remove and replace the cartridges
Toner-cartridge information
This printer indicates when the toner-cartridge level is low and very low. The actual toner-cartridge life remaining
can vary. Consider having a replacement cartridge available to install when print quality is no longer acceptable.
To purchase cartridges or check cartridge compatibility for the printer, go to HP SureSupply at www.hp.com/go/
suresupply. Scroll to the bottom of the page and verify that the country/region is correct.
The printer uses four colors and has a dierent toner cartridge for each color: yellow (Y), magenta (M), cyan (C),
and black (K). The toner cartridges are inside the front door.
Table 3-8 Toner-cartridge information
Item Description Cartridge number Part number
HP 659A Black Original LaserJet Toner
Cartridge
Standard-yield replacement black toner
cartridge
659A W2010A
HP 659X High Yield Black Original
LaserJet Toner Cartridge
High-yield replacement black toner
cartridge
659X W2010X
HP 659A Cyan Original LaserJet Toner
Cartridge
Standard-yield replacement cyan toner
cartridge
659A W2011A
HP 659X High Yield Cyan Original
LaserJet Toner Cartridge
High-yield replacement cyan toner
cartridge
659X W2011X
HP 659A Magenta Original LaserJet
Toner Cartridge
Standard-yield replacement magenta
toner cartridge
659A W2013A
HP 659X High Yield Magenta Original
LaserJet Toner Cartridge
High-yield replacement magenta toner
cartridge
659X W2013X
HP 659A Yellow Original LaserJet Toner
Cartridge
Standard-yield replacement yellow
toner cartridge
659A W2012A
HP 659X High Yield Yellow Original
LaserJet Toner Cartridge
High-yield replacement yellow toner
cartridge
659X W2012X
NOTE: High-yield toner cartridges contain more toner than standard cartridges for increased page yield. For
more information, go to www.hp.com/go/learnaboutsupplies.
Do not remove the toner cartridge from its package until it is time to replace it.
CAUTION: To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes.
Cover the green imaging drum if the toner cartridge must be removed from the printer for an extended period of
time.
CAUTION: Do not touch the developer roller. Fingerprints on the developer roller can cause print-quality
problems.
The following illustration shows the toner-cartridge components.
