User's Manual
Table Of Contents
- Printer overview
- Paper trays
- Supplies, accessories, and parts
- Order supplies, accessories, and parts
- Dynamic security
- Configure the HP toner-cartridge-protection supply settings
- Introduction
- Enable or disable the Cartridge Policy feature
- Use the printer control panel to enable the Cartridge Policy feature
- Use the printer control panel to disable the Cartridge Policy feature
- Use the HP Embedded Web Server (EWS) to enable the Cartridge Policy feature
- Use the HP Embedded Web Server (EWS) to disable the Cartridge Policy feature
- Troubleshoot Cartridge Policy control panel error messages
- Enable or disable the Cartridge Protection feature
- Use the printer control panel to enable the Cartridge Protection feature
- Use the printer control panel to disable the Cartridge Protection feature
- Use the HP Embedded Web Server (EWS) to enable the Cartridge Protection feature
- Use the HP Embedded Web Server (EWS) to disable the Cartridge Protection feature
- Troubleshoot Cartridge Protection control panel error messages
- Replace the toner cartridges
- Replace the imaging drums
- Replace the toner-collection unit
- Replace the staple cartridge (M776zs model only)
- Copy
- Scan
- Set up Scan to Email
- Set up Scan to Network Folder
- Introduction
- Before you begin
- Step one: Access the HP Embedded Web Server (EWS)
- Step two: Set up Scan to Network Folder
- Method one: Use the Scan to Network Folder Wizard
- Method two: Use Scan to Network Folder Setup
- Step one: Begin the configuration
- Step two: Configure the Scan to Network Folder settings
- Step one: Begin the configuration
- Dialog one: Set the Quick Set name, description, and options for user interaction at the control pan ...
- Dialog two: Folder Settings
- Dialog three: Notification Settings
- Dialog four: Scan Settings
- Dialog five: File Settings
- Dialog six: Summary
- Step three: Complete the configuration
- Set up Scan to SharePoint
- Set up Scan to USB Drive
- Scan to email
- Scan to job storage
- Scan to network folder
- Scan to SharePoint
- Scan to USB drive
- Use HP JetAdvantage business solutions
- Additional scan tasks
- Fax
- Manage the printer
- Solve problems
- Customer support
- Control panel help system
- Reset factory settings
- A “Cartridge is low” or “Cartridge is very low” message displays on the printer control panel
- Printer does not pick up paper or misfeeds
- Clear paper jams
- Introduction
- Paper jam locations
- Auto-navigation for clearing paper jams
- Experiencing frequent or recurring paper jams?
- Clear paper jams in the document feeder - 31.13.yz
- Clear paper jams in Tray 1 (13.A1)
- Clear paper jams in Tray 2 (13.A2)
- Clear paper jams in the fuser (13.B9, 13.B2, 13.FF)
- Clear paper jams in the output bin (13.E1)
- Clear paper jams in the duplex area (13.D3)
- Clear paper jams in the 550-sheet trays (13.A3, 13.A4)
- Clear paper jams in the 2 x 550 paper trays (13.A4, 13.A5)
- Clear paper jams in the 2,700-sheet high-capacity input paper trays (13.A3, 13.A4, 13.A5, 13.A7)
- Resolving color print quality problems
- Introduction
- Troubleshoot print quality
- Troubleshoot color quality
- Troubleshoot image defects
- Improve copy image quality
- Improve scan image quality
- Improve fax image quality
- Solve wired network problems
- Introduction
- Poor physical connection
- The computer is unable to communicate with the printer
- The printer is using incorrect link and duplex settings for the network
- New software programs might be causing compatibility problems
- The computer or workstation might be set up incorrectly
- The printer is disabled, or other network settings are incorrect
- Solve wireless network problems
- Introduction
- Wireless connectivity checklist
- The printer does not print after the wireless configuration completes
- The printer does not print, and the computer has a third-party firewall installed
- The wireless connection does not work after moving the wireless router or printer
- Cannot connect more computers to the wireless printer
- The wireless printer loses communication when connected to a VPN
- The network does not appear in the wireless networks list
- The wireless network is not functioning
- Reduce interference on a wireless network
- Solve fax problems
- Checklist for solving fax problems
- General fax problems
- The fax failed to send
- No fax address book button displays
- Not able to locate the Fax settings in HP Web Jetadmin
- The header is appended to the top of the page when the overlay option is enabled
- A mix of names and numbers is in the recipients box
- A one-page fax prints as two pages
- A document stops in the document feeder in the middle of faxing
- The volume for sounds coming from the fax accessory is too high or too low
- Index
NOTE: The Windows software installer installs the HP Smart Device Agent Base service. The le size is less than
100 kb. Its only function is to check for printers connected via USB hourly. No data is collected. If a USB printer is
found, it then tries to locate a JetAdvantage Management Connector (JAMc) instance on the network. If a JAMc is
found, the HP Smart Device Agent Base is securely upgraded to a full Smart Device Agent from JAMc, which will
then allow printed pages to be accounted for in a Managed Print Services (MPS) account. The driver-only web
packs downloaded from www.hp.com for the printer and installed through the Add Printer wizard do not install
this service.
To uninstall the service, open the Control Panel, select Programs or Programs and Features, and then select Add/
Remove Programs or Uninstall a Program to remove the service. The le name is HPSmartDeviceAgentBase.
Mobile printing solutions
HP oers multiple mobile printing solutions to enable easy printing to an HP printer from a laptop, tablet,
smartphone, or other mobile device.
To see the full list and to determine the best choice, go to www.hp.com/go/MobilePrinting.
NOTE: Update the printer rmware to ensure all mobile printing capabilities are supported.
● Wi-Fi Direct (wireless models only, with HP Jetdirect 3100w BLE/NFC/Wireless accessory installed)
● HP ePrint via email (Requires HP Web Services to be enabled and the printer to be registered with
HP Connected)
● HP Smart app
● Google Cloud Print
● AirPrint
● Android Printing
● HP Roam
Printer dimensions
Make sure your printer environment is large enough to accommodate the printer.
Table
1-10 Dimensions for the base printer—M776dn
Dimension Printer fully closed Printer fully opened
Height 710 mm (28 in) 1025 mm (40.4 in)
Depth 663 mm (26.1 in) 1103 mm (43.4 in)
Width 585 mm (23 in) 1051 mm (41.4 in)
Weight 70.9 kg (156.3) 70.9 kg (156.3)
Table 1-11 Dimensions for the M776z printer
Dimension Printer and accessories fully closed Printer and accessories fully opened
Height 1034 mm (40.7 in) 1475 mm (58.1 in)
Depth 712 mm (28 in) 1115 mm (43.9 in)
14 Chapter 1 Printer overview ENWW
