Control-panel view
The control panel provides access to the printer features and indicates the current status of the printer.
●
How to use the touchscreen control panel
NOTE: Tilt the control panel for easier viewing.
The Home screen provides access to the printer features and indicates the current status of the printer.
Return to the Home screen at any time by touching the Home button. Touch the Home button on the left
side of the printer control panel, or touch the Home button in the upper-left corner of most screens.
NOTE: The features that appear on the Home screen can vary, depending on the printer conguration.
Figure 1-1 Control-panel view
?i
12:42 PM
1
7
6
23
45
8
Item Control Description
1
Home button
Touch the Home button to return to the Home screen.
2 Reset button The Reset button returns the printer to default settings and is always present if users
are not logged in. The Reset button is not present when the Sign Out button is present.
Touch the Reset button to resume and release jobs from the previous pause state and
interrupt mode, reset the quick copy count in the copy count eld, exit special modes,
reset the display language and the keyboard layout.
3 Sign In or Sign Out button Touch the Sign In button to access secured features.
Touch the Sign Out button to sign out of the printer. The printer restores all options to
the default settings.
NOTE: This button displays only if the administrator has congured the printer to
require permission for access to features.
ENWW Printer views 7
