User's Manual
Table Of Contents
- Printer overview
- Paper trays
- Supplies, accessories, and parts
- Order supplies, accessories, and parts
- Dynamic security
- Configure the HP toner-cartridge-protection supply settings
- Introduction
- Enable or disable the Cartridge Policy feature
- Use the printer control panel to enable the Cartridge Policy feature
- Use the printer control panel to disable the Cartridge Policy feature
- Use the HP Embedded Web Server (EWS) to enable the Cartridge Policy feature
- Use the HP Embedded Web Server (EWS) to disable the Cartridge Policy feature
- Troubleshoot Cartridge Policy control panel error messages
- Enable or disable the Cartridge Protection feature
- Use the printer control panel to enable the Cartridge Protection feature
- Use the printer control panel to disable the Cartridge Protection feature
- Use the HP Embedded Web Server (EWS) to enable the Cartridge Protection feature
- Use the HP Embedded Web Server (EWS) to disable the Cartridge Protection feature
- Troubleshoot Cartridge Protection control panel error messages
- Replace the toner cartridges
- Replace the imaging drums
- Replace the toner-collection unit
- Replace the staple cartridge (M776zs model only)
- Copy
- Scan
- Set up Scan to Email
- Set up Scan to Network Folder
- Introduction
- Before you begin
- Step one: Access the HP Embedded Web Server (EWS)
- Step two: Set up Scan to Network Folder
- Method one: Use the Scan to Network Folder Wizard
- Method two: Use Scan to Network Folder Setup
- Step one: Begin the configuration
- Step two: Configure the Scan to Network Folder settings
- Step one: Begin the configuration
- Dialog one: Set the Quick Set name, description, and options for user interaction at the control pan ...
- Dialog two: Folder Settings
- Dialog three: Notification Settings
- Dialog four: Scan Settings
- Dialog five: File Settings
- Dialog six: Summary
- Step three: Complete the configuration
- Set up Scan to SharePoint
- Set up Scan to USB Drive
- Scan to email
- Scan to job storage
- Scan to network folder
- Scan to SharePoint
- Scan to USB drive
- Use HP JetAdvantage business solutions
- Additional scan tasks
- Fax
- Manage the printer
- Solve problems
- Customer support
- Control panel help system
- Reset factory settings
- A “Cartridge is low” or “Cartridge is very low” message displays on the printer control panel
- Printer does not pick up paper or misfeeds
- Clear paper jams
- Introduction
- Paper jam locations
- Auto-navigation for clearing paper jams
- Experiencing frequent or recurring paper jams?
- Clear paper jams in the document feeder - 31.13.yz
- Clear paper jams in Tray 1 (13.A1)
- Clear paper jams in Tray 2 (13.A2)
- Clear paper jams in the fuser (13.B9, 13.B2, 13.FF)
- Clear paper jams in the output bin (13.E1)
- Clear paper jams in the duplex area (13.D3)
- Clear paper jams in the 550-sheet trays (13.A3, 13.A4)
- Clear paper jams in the 2 x 550 paper trays (13.A4, 13.A5)
- Clear paper jams in the 2,700-sheet high-capacity input paper trays (13.A3, 13.A4, 13.A5, 13.A7)
- Resolving color print quality problems
- Introduction
- Troubleshoot print quality
- Troubleshoot color quality
- Troubleshoot image defects
- Improve copy image quality
- Improve scan image quality
- Improve fax image quality
- Solve wired network problems
- Introduction
- Poor physical connection
- The computer is unable to communicate with the printer
- The printer is using incorrect link and duplex settings for the network
- New software programs might be causing compatibility problems
- The computer or workstation might be set up incorrectly
- The printer is disabled, or other network settings are incorrect
- Solve wireless network problems
- Introduction
- Wireless connectivity checklist
- The printer does not print after the wireless configuration completes
- The printer does not print, and the computer has a third-party firewall installed
- The wireless connection does not work after moving the wireless router or printer
- Cannot connect more computers to the wireless printer
- The wireless printer loses communication when connected to a VPN
- The network does not appear in the wireless networks list
- The wireless network is not functioning
- Reduce interference on a wireless network
- Solve fax problems
- Checklist for solving fax problems
- General fax problems
- The fax failed to send
- No fax address book button displays
- Not able to locate the Fax settings in HP Web Jetadmin
- The header is appended to the top of the page when the overlay option is enabled
- A mix of names and numbers is in the recipients box
- A one-page fax prints as two pages
- A document stops in the document feeder in the middle of faxing
- The volume for sounds coming from the fax accessory is too high or too low
- Index
Table 8-4 HP Embedded Web Server Scan/Digital Send tab (continued)
Menu Description
Scan to Network Folder Congure the network folder settings for digital sending, including the following:
● Settings for Quick Sets jobs saved in a network folder
● Settings for notications
● Default scan settings for jobs saved in a network folder
● Default le settings for jobs saved in a network folder
Scan to SharePoint®
(Flow models only)
Congure the SharePoint settings for digital sending, including the following:
● Settings for Quick Sets jobs saved in a document library on the SharePoint site
● Default settings for jobs saved in a document library on the SharePoint site
Scan to USB Drive Congure the USB settings for digital sending, including the following:
● Settings for Quick Sets jobs saved on a USB ash drive
● Settings for notications
● Default scan settings for jobs saved on a USB ash drive
● Default le settings for jobs saved on a USB ash drive
Contacts Manage contacts, including the following:
● Add email addresses into the printer one at a time.
● Import a large list of frequently-used email addresses on to the printer all at once,
rather than adding them one at a time.
● Export contacts from the printer into a .CSV le on the computer to use as a data
backup, or import the records onto another HP printer.
● Edit email addresses that have already been saved in the printer.
Preferences Manage general scanning settings.
Email and Scan to Network Folder Quick
Setup Wizards
Congure the printer to send scanned images as email attachments.
Congure the printer to save scanned images to network-folder Quick Sets. Quick Sets
provide easy access to les saved on the network.
Digital Sending Software Setup Congure settings related to using optional Digital Sending software.
Fax tab
Refer to the table for settings in the Fax tab.
ENWW Advanced conguration with the HP Embedded Web Server (EWS) 183
