Step two: Congure the Scan to Network Folder settings
Use the following procedure to complete Scan to Network Folder setup.
●
Step one: Begin the conguration
●
Dialog one: Set the Quick Set name, description, and options for user interaction at the control panel
●
Dialog two: Folder Settings
●
Dialog three: Notication Settings
●
Dialog four: Scan Settings
●
Dialog ve: File Settings
●
Dialog six: Summary
Step one: Begin the conguration
Use the following steps to begin conguration.
1. On the Scan to Network Folder Setup page, select the Enable Scan to Network Folder check box. If this box
is not selected, the feature is unavailable at the printer control panel.
2. In the Scan to Network Folder area of the left navigation pane, click Quick Sets. Click Add to open the Quick
Sets Setup dialog.
NOTE: Quick Sets are shortcut jobs that can be accessed on the printer Home screen or within the Quick
Sets application.
NOTE: The Scan to Network Folder feature can be minimally congured without creating a Quick Set.
However, without the Quick Set, users must enter the destination folder information at the control panel for
each scan job. A Quick Set is required to include Scan to Network Folder metadata.
Complete all of the settings in the Quick Set Setup to fully congure the Scan to Network Folder feature.
Dialog one: Set the Quick Set name, description, and options for user interaction at the control panel
Set the Quick Set details for user interaction at the printer's control panel.
Use the Set the button location for the Quick Set and options for user interaction at the control panel dialog to
congure where the Quick Set button will display on the printer control panel and to congure the level of user
interaction at the printer control panel.
1. In the Quick Set Name eld, type a title.
NOTE: Name the Quick Set something that users can understand quickly (e.g., "Scan and save to a
folder").
2. In the Quick Set Description eld, type a description explaining what the Quick Set will save.
3. From the Quick Set Start Option list, select one of the following options:
● Option one: Enter application, then user presses Start.
● Option two: Start instantly upon selection.
Select one of the following prompt options :
