User's Manual
Table Of Contents
- HP 3PAR Storage Replication Adapter 5.5.2 for VMware® vCenter Site Recovery Manager™ User Guide
- Contents
- 1 Introduction
- 2 VMware vCenter Site Recovery Manager overview
- 3 Supported configurations
- 4 HP 3PAR SRA installation and configuration prerequisites
- 5 Installing HP 3PAR SRA
- 6 HP 3PAR storage system setup
- 7 Configuring VMware vCenter Site Recovery Manager and HP 3PAR SRA
- 8 Recovery and failback
- 9 HP 3PAR SRA for the VMware SRM 5.5 utility
- 10 Partial licensing
- 11 HP 3PAR SRA 5.5.2 SRM vs HP 3PAR Remote Copy state diagram
- 12 Special notes
- 13 Support and other resources
- 14 Documentation feedback
NOTE: You must accept and validate the HP 3PAR StoreServ certificate using the TPDSrm
utility before you configure SRM with HP 3PAR StoreServ Storage System. If you do not validate
the certificate, connection to HP 3PAR StoreServ is denied.
• TPDSrm.exe removecert—To delete the accepted HP 3PAR StoreServ certificate from the
cache memory.
If you have configured an SLD remote copy environment with three HP 3PAR StoreServ Storage
systems (A, B, and C), where A—B is configured in synchronous mode, A—C in asynchronous
periodic mode, and B—C is the standby link in asynchronous periodic mode. SRM/SRA is
configured between HP 3PAR StoreServ Storage systems A and C, then HP 3PAR SRA requires
that you accept and validate the HP 3PAR StoreServ Storage SSL certificate for the primary and
secondary HP 3PAR StoreServ Storage systems on both the Protected and Recovery sites.
NOTE: You must accept the certificate when the link between A and C is UP.
For example, HP 3PAR StoreServ A and SRM Server 1 are part of the protected site. HP
3PAR StoreServ B and SRM Server 2 are part of the recovery site. In SRM Server 1, you
must accept and validate the HP 3PAR StoreServ A and HP 3PAR StoreServ B certificates.
Perform a similar procedure for SRM Server 2.
22 Configuring VMware vCenter Site Recovery Manager and HP 3PAR SRA
