Displaying the Remote Copy groups configuration
1. Display the Remote Copy groups configurations on the protected site.
root@inodee2023:~# showrcopy
Remote Copy System Information
Status: Started, Normal
Target Information
Name ID Type Status Options Policy
s230 19 IP ready mirror_config
Link Information
Target Node Address Status Options
s230 0 10.100.33.230 Up
s230 1 10.101.33.230 Up
receive 0 receive Up
receive 1 receive Up
Group Information
Name Target Status Role Mode Options
srm_1 s230 Started Primary Sync
LocalVV ID RemoteVV ID SyncStatus LastSyncTime
srm_vol1 4213 srm_vol1 4237 Synced NA
srm_vol2 4214 srm_vol2 4238 Synced NA
srm_vol3 4215 srm_vol3 4239 Synced NA
2. Display the Remote Copy groups configurations on the recovery site.
root@snodec242:~# showrcopy
Remote Copy System Information
Status: Started, Normal
Target Information
Name ID Type Status Options Policy
s388 18 IP ready mirror_config
Link Information
Target Node Address Status Options
s388 0 10.100.33.88 Up
s388 1 10.101.33.88 Up
receive 0 receive Up
receive 1 receive Up
Group Information
Name Target Status Role Mode Options
srm_1.r388 s388 Started Secondary Sync
LocalVV ID RemoteVV ID SyncStatus LastSyncTime
srm_vol1 4237 srm_vol1 4213 Synced NA
srm_vol2 4238 srm_vol2 4214 Synced NA
srm_vol3 4239 srm_vol3 4215 Synced NA
Configuring Remote Copy with IP between the protected and recovery sites 17
