Introduction 6
Introduction
Virtual Connect documentation
The following Virtual Connect documentation is available on the HP website
(http://www.hp.com/go/bladesystem/documentation
):
• HP Virtual Connect for c-Class BladeSystem User Guide
This guide provides details for the Virtual Connect GUI, including descriptions of screen contents and
steps to set up domains, profiles, networks, and storage.
• HP Virtual Connect for c-Class BladeSystem Setup and Installation Guide
This guide provides hardware installation and configuration information for initial setup of a Virtual
Connect solution. The guide also provides Virtual Connect module component and LED descriptions
and guidelines for module installation and upgrades.
• HP Virtual Connect for c-Class Command Line Interface User Guide
This guide provides information for using the Virtual Connect Command Line Interface, including use
scenarios and complete descriptions of all subcommands and managed elements.
• HP Virtual Connect Ethernet Networking Scenario Cookbook: Single Domain Scenarios
This guide helps new Virtual Connect users understand the concepts of and implement steps for
integrating Virtual Connect into a Cisco network. The simplistic scenarios in this guide cover a range
of typical building blocks administrators can use when designing a Virtual Connect solution.
• HP Virtual Connect Fibre Channel Networking Scenarios Cookbook
This guide details the concepts and implementation steps for integrating HP BladeSystem Virtual
Connect Fibre Channel components into an existing SAN fabric. The scenarios in this guide are
simplistic while covering a range of typical building blocks to use when designing a solution.
• HP BladeSystem c-Class Virtual Connect Support Utility User Guide
This guide provides instructions on using the Virtual Connect Support Utility, which enables
administrators to upgrade VC-Enet and VC-FC firmware and to perform other maintenance tasks
remotely on both HP BladeSystem c7000 and c3000 enclosures using a standalone, Windows-
based command line utility.
• Release Notes
Release notes document new features, resolved issues, known issues, and important notes for each
release of the Virtual Connect Manager and support utility.
