Domain management 48
The VC-FC SNMP settings apply to all VC-FC modules in the VC domain.
The following table describes the fields within the SNMP Configuration screen.
Field name Description
Enable SNMP Select to enable SNMP
System Contact Specify a contact name for this system when SNMP is enabled
Read Community
Controls SNMP read access when SNMP is enabled. The default value for read
community string is "public". The read community string must always be set
when SNMP is enabled. The maximum length is 39 characters.
SNMP Trap Destinations SNMP trap destination table.
Destination
User-designated name for the trap destination. The Destination name must be
unique.
IP Address IPv4 address or DNS name for the trap destination
Community String
The Community String acts like a password for a given trap destination. The
trap receiving application can use the community string to filter the incoming
traps.
Default: public
Format Format of the new trap. Select SNMPv1 or SNMPv2.
To add a trap destination, right-click on the header row of the destination table, and then select Add
Destination. See "Adding an SNMP trap destination (on page 46)."
